Event Specification

 Map Region : lat:-  lon:-

  North
West   East
  South
Show Cities
Show Foreign Cities
Show Fault Mechanism
Show Province Boundaries
Show Stations
Map Title

Magnitude
3
Date & Time (UTC) 2017-09-11 13:38:42.2
Date & Time (Local) 1396/6/20  18:08:42.2
Location Lat:34.23 Lon: 62.143
Region Afghanistan, 14 km South of Herat
Nearest Cities
14 km South of Herat, Afghanistan Province
135 km South East of Taybad, Khorasan(center) Province
137 km South East of Void, Khorasan(center) Province
140 km North East of Yazdan, Khorasan(south) Province
149 km South East of Karat, Khorasan(center) Province
Depth 15 km
Agency
Faults within 150 km:
DORUNEH_F (Length: 713 km) , Distance to epicenter: 119 km
PATARGAN_F (Length: 52 km) , Distance to epicenter: 140 km
Number of Phases 7
RMS 0.3
Number of Stations 5
Error in Latitude >7.1 km
Error in Longitude 7.7 km
Error in Depth 9.3 km

Download waveform in seisan format

to download seisan software Click here

to access information about IIEES stations Click here

Amplitude

UIDAgencyStationComponentAmplitudePeriodArrival TimeProccessing TimeSignal Clip
119497IIEESSHRTN 189.90.352017-09-11 13:39:372017-09-13 10:16:00n
119498IIEESSHRTE 134.10.352017-09-11 13:39:392017-09-13 10:16:00n
119499IIEESTABSN 11.90.592017-09-11 13:41:102017-09-13 10:16:00n

Phase

AgencyStationComponentPhase TypePhase QualityFirst MotionObserved Arrival TimeTime ResidualLoc. FlagInput WeightDistanceAzimuth
IIEESSHRTZ Pg E2017-09-11 13:39:120.02y183250
IIEESSHRTN Sg E2017-09-11 13:39:340.14y183250
IIEESBSRNZ Pn E2017-09-11 13:39:36-0.23y377229
IIEESTABSZ Pn E2017-09-11 13:39:47-0.15y469264
IIEESTABSN Sg E2017-09-11 13:40:52-0.23y469264
IIEESSHROZ Pn E2017-09-11 13:40:030.04y593291
IIEESYZKHZ Pn E2017-09-11 13:40:210.68y732256
