Magnitude
:4.3
Date & Time (UTC) 2019-07-16 18:15:27.6
Date & Time (Local) 98/4/25  22:45:27.6
Location Lat:28.37 Lon: 56.98
Region Kerman Province, 81 km South-West of Jiroft
Nearest Cities
11 km North East of Sarkhan, Kerman Province
38 km North West of Hurpasefid, Kerman Province
40 km South West of Dolatabad, Kerman Province
44 km North West of Faryab, Kerman Province
52 km North West of Mehrueye-e paeen, Kerman Province
Depth 15 km
Agency
Faults within 150 km:
MAIN_ZAGROS_R_F (Length: 1106 km) , Distance to epicenter: 41 km
SABZEVARAN_F (Length: 190 km) , Distance to epicenter: 74 km
ZENDAN_MINAB_F_Z1 (Length: 183 km) , Distance to epicenter: 80 km
Number of Phases 20
RMS 0.8
Number of Stations 13
Error in Latitude >3 km
Error in Longitude 0 km
Error in Depth 14 km

Download waveform in seisan format

to download seisan software Click here

to access information about IIEES stations Click here

Amplitude

UIDAgencyStationComponentAmplitudePeriodArrival TimeProccessing TimeSignal Clip
144304IIEES SCBNDSZ 930012019-07-16 18:15:512019-07-16 10:59:00n
144305IIEES SCKRBRZ 330012019-07-16 18:16:002019-07-16 10:59:00n
144306IIEES SCLMD1Z 87012019-07-16 18:17:522019-07-16 10:59:00n
144307IIEES SCZHSFZ 24012019-07-16 18:17:262019-07-16 10:59:00n
144308IIEES SCCHBRZ 47012019-07-16 18:16:502019-07-16 10:59:00n
144309IIEES SCYZKHZ 26012019-07-16 18:16:562019-07-16 10:59:00n
144310IIEES SCTABSZ 47012019-07-16 18:18:342019-07-16 10:59:00n
144311IIEES SCKLNJZ 22012019-07-16 18:17:532019-07-16 10:59:00n
144312IIEES SCSHROZ 5612019-07-16 18:19:502019-07-16 10:59:00n
144313IIEES SCKHMZZ 6512019-07-16 18:17:262019-07-16 10:59:00n

Phase

AgencyStationComponentPhase TypePhase QualityFirst MotionObserved Arrival TimeTime ResidualLoc. FlagInput WeightDistanceAzimuth
IIEES SCBNDSN IS I2019-07-16 18:16:070.6y133216
IIEES SCBNDSZ IP I2019-07-16 18:15:500.7y133216
IIEES SCKRBRZ IP I2019-07-16 18:15:56-0.5y177353
IIEES SCLMD1Z IP I2019-07-16 18:16:23-1y389253
IIEES SCZHSFZ IP I2019-07-16 18:16:251.2y40070
IIEES SCCHBRZ IP I2019-07-16 18:16:32-0.8y467131
IIEES SCYZKHZ IP I2019-07-16 18:16:370.1y500333
IIEES SCTABSZ IP I2019-07-16 18:16:480.6y5891
IIEES SCKLNJZ IP I2019-07-16 18:16:48-0.9y600299
IIEES SCSHROZ IP I2019-07-16 18:17:20-0.3y856354
IIEES SCKHMZZ IP I2019-07-16 18:17:25-1y900312
IIEES SCCHTHZ IP I2019-07-16 18:17:400.2y1000327
IIEES SCBNDS1816 2019-07-16 18:16:09y133216
IIEES SCKRBR1816 2019-07-16 18:16:25y177353
IIEES SCLMD11817 2019-07-16 18:17:46y389253
IIEES SCZHSF1817 2019-07-16 18:17:29y40070
IIEES SCCHBR1817 2019-07-16 18:17:20y467131
IIEES SCYZKH1818 2019-07-16 18:18:25y500333
IIEES SCTABS1818 2019-07-16 18:18:40y5891
IIEES SCKLNJ1817 2019-07-16 18:17:52y600299
