Magnitude
:3.7
Date & Time (UTC) 2020-05-05 02:03:41.2
Date & Time (Local) 99/2/16  06:33:41.2
Location Lat:34.12 Lon: 45.63
Region Kermanshah Province, 26 km -West of Gilan-E-Gharb
Nearest Cities
26 km West of Gilan-E-Gharb, Kermanshah Province
27 km North of Sumar, Kermanshah Province
30 km South West of Chub baghan, Kermanshah Province
32 km North West of Nian, Kermanshah Province
34 km South East of Khosravi, Kermanshah Province
Depth 11 km
Agency
Faults within 150 km:
ZFF4 (Length: 128 km) , Distance to epicenter: 25 km
MFF7 (Length: 99 km) , Distance to epicenter: 31 km
MFF8 (Length: 48 km) , Distance to epicenter: 47 km
Number of Phases 13
RMS 0.6
Number of Stations 13
Error in Latitude >3 km
Error in Longitude 0 km
Error in Depth 8 km

Download waveform in seisan format

to download seisan software Click here

to access information about IIEES stations Click here

Amplitude

UIDAgencyStationComponentAmplitudePeriodArrival TimeProccessing TimeSignal Clip
153551IIEES SCILBAZ 80012020-05-05 02:04:262020-05-06 01:29:00n
153552IIEES SCSNGEZ 66012020-05-05 02:04:422020-05-06 01:29:00n
153553IIEES SCSRSLZ 95012020-05-05 02:04:492020-05-06 01:29:00n
153554IIEES SCMAHBZ 44012020-05-05 02:05:072020-05-06 01:29:00n
153555IIEES SCGTMRZ 8912020-05-05 02:05:462020-05-06 01:29:00n
153556IIEES SCAZRZ 69012020-05-05 02:05:512020-05-06 01:29:00n
153557IIEES SCZNJKZ 1812020-05-05 02:05:522020-05-06 01:29:00n
153558IIEES SCKHMZZ 4012020-05-05 02:05:502020-05-06 01:29:00n
153559IIEES SCAMISZ 7412020-05-05 02:05:322020-05-06 01:29:00n
153560IIEES SCGRMIZ 1212020-05-05 02:06:412020-05-06 01:29:00n
153561IIEES SCGRMIZ 5.70.452020-05-05 02:05:042020-05-06 01:29:00n

Phase

AgencyStationComponentPhase TypePhase QualityFirst MotionObserved Arrival TimeTime ResidualLoc. FlagInput WeightDistanceAzimuth
IIEES SCILBAZ IP I2020-05-05 02:03:54-0.3y77135
IIEES SCSNGEN IS I2020-05-05 02:04:35-0.9y18956
IIEES SCSNGEZ IP I2020-05-05 02:04:141.8y18956
IIEES SCSRSLN IS I2020-05-05 02:04:460y233356
IIEES SCSRSLZ IP I2020-05-05 02:04:17-0.5y233356
IIEES SCMAHBZ IP I2020-05-05 02:04:25-0.1y2891
IIEES SCGTMRZ IP I2020-05-05 02:04:35-0.2y378119
IIEES SCAZRZ IP I2020-05-05 02:04:390.8y4005
IIEES SCZNJKZ IP I2020-05-05 02:04:390.2y40044
IIEES SCQABGZ IP I2020-05-05 02:04:390.3y40064
IIEES SCKHMZZ IP I2020-05-05 02:04:400.8y40096
IIEES SCAMISZ IP I2020-05-05 02:04:430y433128
IIEES SCGRMIZ IP I2020-05-05 02:04:57-1y55621
