Date & Time (UTC) 2021-12-21 01:14:28.5
Date & Time (Local) 1400/9/30  04:44:28.5
Location Lat:34.889 Lon: 45.7
Region Iraq, 19 km North-West of Tazehabad
Nearest Cities
15 km North of Tappeh rash, Kermanshah Province
19 km North West of Tazehabad, Kermanshah Province
22 km North West of Gardehnu, Kermanshah Province
25 km North West of Dehsheykh, Kermanshah Province
30 km South West of Markhil, Kermanshah Province
Depth 15 km
Faults within 150 km:
MFF8 (Length: 48 km) , Distance to epicenter: 19 km
HZF4 (Length: 492 km) , Distance to epicenter: 29 km
PIRANSHAHR_F (Length: 253 km) , Distance to epicenter: 79 km
Number of Phases 12
RMS 0.5
Number of Stations 12
Error in Latitude >3.3 km
Error in Longitude 3.3 km
Error in Depth 9.5 km

Download waveform in seisan format

to download seisan software Click here

to access information about IIEES stations Click here


UIDAgencyStationComponentAmplitudePeriodArrival TimeProccessing TimeSignal Clip
167498IIEES SCILBAZ 112021-12-21 01:14:522021-12-21 06:24:00n
167499IIEES SCMAHBZ 212021-12-21 01:15:022021-12-21 06:24:00n
167500IIEES SCASAOZ 0.112021-12-21 01:15:262021-12-21 06:24:00n
167501IIEES SCKHMZZ 0.112021-12-21 01:15:272021-12-21 06:24:00n
167502IIEES SCGTMRZ 0.212021-12-21 01:15:272021-12-21 06:24:00n
167503IIEES SCMRDZ 0.212021-12-21 01:15:292021-12-21 06:24:00n
167504IIEES SCMAKUZ 0.0112021-12-21 01:15:382021-12-21 06:24:00n
167505IIEES SCCHTHZ 0.0312021-12-21 01:15:382021-12-21 06:24:00n
167506IIEES SCGHVRZ 0.112021-12-21 01:15:402021-12-21 06:24:00n


AgencyStationComponentPhase TypePhase QualityFirst MotionObserved Arrival TimeTime ResidualLoc. FlagInput WeightDistanceAzimuth
IIEES SCILBAZ EPg E2021-12-21 01:14:52-0.1y0148162
IIEES SCSNGEZ EPg E2021-12-21 01:14:530.2y015281
IIEES SCMAHBZ EPn E2021-12-21 01:15:020.2y02080
IIEES SCAZRZ EPn E2021-12-21 01:15:140y03105
IIEES SCZNJKZ EPn E2021-12-21 01:15:16-0.9y033454
IIEES SCASAOZ EPn E2021-12-21 01:15:260.8y039895
IIEES SCKHMZZ EPn E2021-12-21 01:15:27-0.3y0413108
IIEES SCGTMRZ EPn E2021-12-21 01:15:270y0415130
IIEES SCMRDZ EPn E2021-12-21 01:15:290.7y04240
IIEES SCMAKUZ EPn E2021-12-21 01:15:38-0.3y0504350
IIEES SCCHTHZ EPn E2021-12-21 01:15:38-0.8y050677
IIEES SCGHVRZ EPn E2021-12-21 01:15:400.7y051095
