Date & Time (UTC) 2021-12-31 19:31:01.3
Date & Time (Local) 1400/10/10  23:01:01.3
Location Lat:35.315 Lon: 46.523
Region Kurdistan Province, 33 km North-East of Paveh
Nearest Cities
2 km North of Nagol, Kurdistan Province
11 km North East of Razab, Kurdistan Province
13 km North of Bisaran, Kurdistan Province
13 km North West of Avihang, Kurdistan Province
16 km South of Pir-e khafaran, Kurdistan Province
Depth 12 km
Faults within 150 km:
PIRANSHAHR_F (Length: 253 km) , Distance to epicenter: 7 km
SARTAKHT_F (Length: 78 km) , Distance to epicenter: 40 km
MORVARID_F (Length: 24 km) , Distance to epicenter: 48 km
Number of Phases 16
RMS 0.5
Number of Stations 16
Error in Latitude >2.7 km
Error in Longitude 2.7 km
Error in Depth 12.5 km

Download waveform in seisan format

to download seisan software Click here

to access information about IIEES stations Click here


UIDAgencyStationComponentAmplitudePeriodArrival TimeProccessing TimeSignal Clip
167821IIEES SCMAHBZ 312021-12-31 19:31:292022-01-01 07:18:00n
167822IIEES SCILBAZ 0.712021-12-31 19:31:322022-01-01 07:18:00n
167823IIEES SCASAOZ 0.212021-12-31 19:31:502022-01-01 07:18:00n
167824IIEES SCGIDEZ 0.312021-12-31 19:31:522022-01-01 07:18:00n
167825IIEES SCKHMZZ 0.312021-12-31 19:31:532022-01-01 07:18:00n
167826IIEES SCMRDZ 0.312021-12-31 19:31:582022-01-01 07:18:00n
167827IIEES SCGTMRZ 0.212021-12-31 19:31:572022-01-01 07:18:00n
167828IIEES SCGRMIZ 0.0712021-12-31 19:31:592022-01-01 07:18:00n
167829IIEES SCCHTHZ 0.0712021-12-31 19:32:012022-01-01 07:18:00n
167830IIEES SCGHVRZ 0.212021-12-31 19:32:052022-01-01 07:18:00n


AgencyStationComponentPhase TypePhase QualityFirst MotionObserved Arrival TimeTime ResidualLoc. FlagInput WeightDistanceAzimuth
IIEES SCSNGEZ EPg E2021-12-31 19:31:12-2.8n479108
IIEES SCSRSLZ EPg E2021-12-31 19:31:24-0.5y0140315
IIEES SCMAHBZ EPg E2021-12-31 19:31:29-0.4y0177335
IIEES SCILBAZ EPg E2021-12-31 19:31:320.1y0190189
IIEES SCZNJKZ EPn E2021-12-31 19:31:39-0.7y024652
IIEES SCAZRZ EPn E2021-12-31 19:31:430.9y0267350
IIEES SCASAOZ EPn E2021-12-31 19:31:500.2y0331105
IIEES SCGIDEZ EPn E2021-12-31 19:31:520.3y034759
IIEES SCGZVZ EPn E2021-12-31 19:31:563n435470
IIEES SCKHMZZ EPn E2021-12-31 19:31:53-0.4y0361119
IIEES SCMRDZ EPn E2021-12-31 19:31:581y0384349
IIEES SCGTMRZ EPn E2021-12-31 19:31:57-0.8y0396143
IIEES SCGRMIZ EPn E2021-12-31 19:31:59-0.2y040617
IIEES SCCHTHZ EPn E2021-12-31 19:32:01-0.3y042281
IIEES SCGHVRZ EPn E2021-12-31 19:32:050.9y0442102
IIEES SCMAKUZ EPn E2021-12-31 19:32:080.3y0477340
