Event Specification
Magnitude |
2.8 |
| Date & Time (UTC) | 2018-08-17 20:37:56.9 |
| Date & Time (Local) | 1397/5/27 01:07:56.9 |
| Location | Lat:35.809 Lon: 57.683 |
| Region | Khorasan(center) Province, 44 km South of Sabzevar |
Nearest Cities |
|
| 7 km North of Bejdan, Khorasan(center) Province | |
| 8 km North of Tondak, Khorasan(center) Province | |
| 18 km South of Sheshtamad, Khorasan(center) Province | |
| 44 km North West of Ghaleh meidan, Khorasan(center) Province | |
| 44 km South of Sabzevar, Khorasan(center) Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| BALHAR_F (Length: 117 km) , Distance to epicenter: 36 km | |
| SABZEVAR_F (Length: 81 km) , Distance to epicenter: 47 km | |
| BIJVARD_F (Length: 83 km) , Distance to epicenter: 48 km | |
| Number of Phases | 8 |
| RMS | 0.1 |
| Number of Stations | 7 |
| Error in Latitude | >1.8 km |
| Error in Longitude | 3.4 km |
| Error in Depth | 6.5 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 135784 | IIEES | SHRO | E | 212.9 | 0.43 | 2018-08-17 20:38:46 | 2018-08-18 08:29:00 | n |
| 135785 | IIEES | TABS | N | 92.9 | 0.53 | 2018-08-17 20:39:20 | 2018-08-18 08:29:00 | n |
| 135786 | IIEES | SHRT | E | 23.3 | 0.38 | 2018-08-17 20:39:42 | 2018-08-18 08:29:00 | n |
| 135787 | IIEES | SHRT | N | 21.2 | 0.58 | 2018-08-17 20:39:51 | 2018-08-18 08:29:00 | n |
| 135788 | IIEES | BSRN | N | 5.3 | 0.59 | 2018-08-17 20:40:12 | 2018-08-18 08:29:00 | n |
| 135789 | IIEES | NASN | N | 3.4 | 0.56 | 2018-08-17 20:40:53 | 2018-08-18 08:29:00 | n |
| 135790 | IIEES | NASN | E | 3.1 | 0.72 | 2018-08-17 20:40:54 | 2018-08-18 08:29:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | SHRO | Z | Pg | E | 2018-08-17 20:38:22 | -0.05 | y | 152 | 279 | |||
| IIEES | SHRO | E | Sg | E | 2018-08-17 20:38:40 | -0.03 | y | 152 | 279 | |||
| IIEES | BJRD | Z | Pn | E | 2018-08-17 20:38:30 | -0.12 | y | 211 | 353 | |||
| IIEES | TABS | Z | Pn | E | 2018-08-17 20:38:35 | 0.01 | y | 245 | 192 | |||
| IIEES | MRVT | Z | Pn | E | 2018-08-17 20:38:35 | 0.21 | y | 250 | 326 | |||
| IIEES | SHRT | Z | Pn | E | 2018-08-17 20:38:46 | -0.17 | y | 339 | 134 | |||
| IIEES | BSRN | Z | Pn | E | 2018-08-17 20:39:00 | 0.23 | y | 447 | 162 | |||
| IIEES | NASN | Z | Pn | E | 2018-08-17 20:39:14 | -0.07 | y | 559 | 235 | |||
