Event Specification
Magnitude |
3.1 |
| Date & Time (UTC) | 2020-05-09 12:11:31.9 |
| Date & Time (Local) | 1399/2/20 16:41:31.9 |
| Location | Lat:35.83 Lon: 52 |
| Region | Mazandaran Province, 14 km North of Damavand |
Nearest Cities |
|
| 7 km North of Abali, Tehran Province | |
| 14 km North of Damavand, Tehran Province | |
| 15 km North East of Bumehen, Tehran Province | |
| 15 km North East of Rudehen, Tehran Province | |
| 16 km West of Rineh, Mazandaran Province | |
| Depth | 10 km |
| Agency | |
Faults within 150 km: |
|
| MOSHA_F (Length: 234 km) , Distance to epicenter: 9 km | |
| N_TEHRAN_F4 (Length: 115 km) , Distance to epicenter: 19 km | |
| KANDOVAN_F (Length: 90 km) , Distance to epicenter: 37 km | |
| Number of Phases | 14 |
| RMS | 0.5 |
| Number of Stations | 11 |
| Error in Latitude | >2 km |
| Error in Longitude | 0 km |
| Error in Depth | 17 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 153769 | IIEES SC | ANJ | Z | 62 | 1 | 2020-05-09 12:12:20 | 2020-05-11 02:02:00 | n |
| 153770 | IIEES SC | QABG | Z | 25 | 1 | 2020-05-09 12:12:35 | 2020-05-11 02:02:00 | n |
| 153771 | IIEES SC | GIDE | Z | 190 | 1 | 2020-05-09 12:12:45 | 2020-05-11 02:02:00 | n |
| 153772 | IIEES SC | KHMZ | Z | 68 | 1 | 2020-05-09 12:12:53 | 2020-05-11 02:02:00 | n |
| 153773 | IIEES SC | ZNJK | Z | 12 | 1 | 2020-05-09 12:13:12 | 2020-05-11 02:02:00 | n |
| 153774 | IIEES SC | NASN | Z | 22 | 1 | 2020-05-09 12:13:16 | 2020-05-11 02:02:00 | n |
| 153775 | IIEES SC | SHRO | Z | 2.4 | 1 | 2020-05-09 12:12:56 | 2020-05-11 02:02:00 | n |
| 153776 | IIEES SC | MRVT | Z | 5.3 | 1 | 2020-05-09 12:13:19 | 2020-05-11 02:02:00 | n |
| 153777 | IIEES SC | YZKH | Z | 12 | 1 | 2020-05-09 12:13:46 | 2020-05-11 02:02:00 | n |
| 153778 | IIEES SC | GRMI | Z | 4.8 | 1 | 2020-05-09 12:13:36 | 2020-05-11 02:02:00 | n |
| 153779 | IIEES SC | TABS | Z | 4.4 | 1 | 2020-05-09 12:14:25 | 2020-05-11 02:02:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES SC | ANJ | Z | IP | I | 2020-05-09 12:12:00 | -0.5 | y | 177 | 103 | |||
| IIEES SC | GLO | Z | IP | I | 2020-05-09 12:12:02 | 0.7 | n | 4 | 177 | 66 | ||
| IIEES SC | QABG | Z | IP | I | 2020-05-09 12:12:06 | -1 | y | 222 | 266 | |||
| IIEES SC | GIDE | Z | IP | I | 2020-05-09 12:12:07 | 0.1 | y | 222 | 303 | |||
| IIEES SC | KHMZ | Z | IP | I | 2020-05-09 12:12:17 | 0.7 | y | 300 | 219 | |||
| IIEES SC | ZNJK | Z | IP | I | 2020-05-09 12:12:19 | 0.4 | y | 311 | 287 | |||
| IIEES SC | NASN | Z | IP | I | 2020-05-09 12:12:23 | 0 | y | 344 | 167 | |||
| IIEES SC | SHRO | Z | IP | I | 2020-05-09 12:12:25 | 0.4 | y | 366 | 87 | |||
| IIEES SC | MRVT | Z | IP | I | 2020-05-09 12:12:32 | 0 | y | 422 | 61 | |||
| IIEES SC | SNGE | Z | IP | I | 2020-05-09 12:12:40 | 6.7 | n | 4 | 433 | 259 | ||
| IIEES SC | YZKH | Z | IP | I | 2020-05-09 12:12:35 | -0.6 | y | 455 | 148 | |||
| IIEES SC | GRMI | Z | IP | I | 2020-05-09 12:12:41 | 0.2 | y | 489 | 312 | |||
| IIEES SC | TABS | Z | IP | I | 2020-05-09 12:12:45 | 0.1 | y | 522 | 117 | |||
| IIEES SC | KLNJ | Z | IP | I | 2020-05-09 12:12:25 | -21.8 | n | 4 | 533 | 184 | ||
