Event Specification
Magnitude |
2.4 |
| Date & Time (UTC) | 2012-02-23 04:09:14.8 |
| Date & Time (Local) | 1390/12/4 07:39:14.8 |
| Location | Lat:35.01 Lon: 49.8 |
| Region | Markazi Province, 41 km North-West of Tafresh |
Nearest Cities |
|
| 12 km South of Gharqabad, Markazi Province | |
| 14 km South of Nobaran, Markazi Province | |
| 20 km North of Jaghtan, Markazi Province | |
| 22 km West of Qeytaniyeh, Markazi Province | |
| 28 km North West of Bazarjan, Markazi Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| INDES_F (Length: 98 km) , Distance to epicenter: 15 km | |
| KUSHK_E_NOSRAT_F (Length: 230 km) , Distance to epicenter: 30 km | |
| TAFRESH_F (Length: 117 km) , Distance to epicenter: 33 km | |
| Number of Phases | 8 |
| RMS | 0.1 |
| Number of Stations | 5 |
| Error in Latitude | >1.1 km |
| Error in Longitude | 1 km |
| Error in Depth | 3.8 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 81962 | IIEES | THKV | E | 75.7 | 0.44 | 2012-02-23 04:09:57 | 2012-02-23 03:50:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | ASAO | Z | Pg | E | 2012-02-23 04:09:24 | -0.12 | y | 55.7 | 158 | |||
| IIEES | THKV | Z | Pg | E | 2012-02-23 04:09:38 | 0.04 | y | 140 | 44 | |||
| IIEES | THKV | E | Sg | E | 2012-02-23 04:09:55 | -0.04 | y | 140 | 44 | |||
| IIEES | GHVR | Z | Pg | E | 2012-02-23 04:09:39 | 0.12 | y | 145 | 114 | |||
| IIEES | CHTH | Z | Pg | E | 2012-02-23 04:09:40 | 0.02 | y | 156 | 50 | |||
| IIEES | CHTH | E | Sg | E | 2012-02-23 04:09:59 | -0.04 | y | 156 | 50 | |||
| IIEES | SNGE | Z | Pn | E | 2012-02-23 04:09:50 | 0.09 | y | 224 | 273 | |||
| IIEES | SNGE | N | Sg | E | 2012-02-23 04:10:18 | -0.07 | y | 224 | 273 | |||
