Event Specification
Magnitude |
2.3 |
| Date & Time (UTC) | 2012-06-29 17:58:29.9 |
| Date & Time (Local) | 1391/4/9 22:28:29.9 |
| Location | Lat:34.19 Lon: 57.15 |
| Region | Khorasan(center) Province, 68 km North-East of Tabas |
Nearest Cities |
|
| 25 km North West of Qaniabad, Khorasan(center) Province | |
| 28 km South East of Eshqabad, Yazd Province | |
| 42 km North West of Reqqeh, Khorasan(center) Province | |
| 44 km North West of Boshravieh, Khorasan(center) Province | |
| 59 km North West of Arsak, Khorasan(center) Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| NAINI_F (Length: 342 km) , Distance to epicenter: 33 km | |
| ESFARDIAR_F (Length: 94 km) , Distance to epicenter: 46 km | |
| TABAS_F1 (Length: 91 km) , Distance to epicenter: 47 km | |
| Number of Phases | 5 |
| RMS | 0.1 |
| Number of Stations | 3 |
| Error in Latitude | >1.6 km |
| Error in Longitude | 2 km |
| Error in Depth | 3.9 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 84303 | IIEES | TABS | E | 191.1 | 0.4 | 2012-06-29 17:58:52 | 2012-06-29 09:55:00 | n |
| 84304 | IIEES | TABS | N | 276.6 | 0.48 | 2012-06-29 17:58:53 | 2012-06-29 09:55:00 | n |
| 84305 | IIEES | SHRO | E | 18.1 | 0.52 | 2012-06-29 17:59:37 | 2012-06-29 09:55:00 | n |
| 84306 | IIEES | SHRT | E | 10.5 | 0.4 | 2012-06-29 17:59:59 | 2012-06-29 09:55:00 | n |
| 84307 | IIEES | SHRT | N | 7.3 | 0.38 | 2012-06-29 18:00:06 | 2012-06-29 09:55:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | TABS | Z | Pg | E | 2012-06-29 17:58:40 | -0.01 | y | 59.5 | 183 | |||
| IIEES | SHRO | Z | Pn | E | 2012-06-29 17:59:05 | -0.14 | y | 227 | 333 | |||
| IIEES | SHRO | E | Sg | E | 2012-06-29 17:59:34 | 0.05 | y | 227 | 333 | |||
| IIEES | SHRT | Z | Pn | E | 2012-06-29 17:59:14 | 0.18 | y | 297 | 101 | |||
| IIEES | SHRT | E | Sg | E | 2012-06-29 17:59:53 | -0.09 | y | 297 | 101 | |||
