Event Specification
Magnitude |
2.8 |
| Date & Time (UTC) | 2013-03-11 12:24:30.7 |
| Date & Time (Local) | 1391/12/21 15:54:30.7 |
| Location | Lat:32.71 Lon: 49.82 |
| Region | Chaharmahal Bakhtiari Province, 37 km South-West of Fereydunshahr |
Nearest Cities |
|
| 4 km North of Durak, Chaharmahal Bakhtiari Province | |
| 16 km South of Masir, Esfahan Province | |
| 30 km South West of Sibak, Esfahan Province | |
| 37 km South West of Fereydunshahr, Esfahan Province | |
| 38 km West of Ghale? sorkh, Esfahan Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| ARDAL_F (Length: 170 km) , Distance to epicenter: 3 km | |
| ZARDKUH_F (Length: 139 km) , Distance to epicenter: 11 km | |
| MAIN_ZAGROS_R_F (Length: 1106 km) , Distance to epicenter: 19 km | |
| Number of Phases | 5 |
| RMS | 0.1 |
| Number of Stations | 4 |
| Error in Latitude | >4 km |
| Error in Longitude | 5 km |
| Error in Depth | 4.4 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 88181 | IIEES | SHGR | N | 222.2 | 0.4 | 2013-03-11 12:25:11 | 2013-03-11 01:06:00 | n |
| 88182 | IIEES | SHGR | E | 236.2 | 0.22 | 2013-03-11 12:25:12 | 2013-03-11 01:06:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | KHMZ | Z | Pg | E | 2013-03-11 12:24:49 | -0.26 | y | 115 | 7 | |||
| IIEES | SHGR | N | Pg | E | 2013-03-11 12:24:50 | -0.01 | y | 117 | 235 | |||
| IIEES | GHVR | Z | Pn | E | 2013-03-11 12:25:07 | 0.01 | y | 237 | 34 | |||
| IIEES | GHVR | N | Sg | E | 2013-03-11 12:25:37 | 0.11 | y | 237 | 34 | |||
| IIEES | SNGE | Z | Pn | E | 2013-03-11 12:25:22 | 0.17 | y | 349 | 320 | |||
