Event Specification
Magnitude |
3.6 |
| Date & Time (UTC) | 2013-04-24 14:32:56.8 |
| Date & Time (Local) | 1392/2/4 19:02:56.8 |
| Location | Lat:28.44 Lon: 51.56 |
| Region | Bushehr Province, 30 km South-East of Khormog |
Nearest Cities |
|
| 8 km North of Baduleh, Bushehr Province | |
| 12 km North of Kaki, Bushehr Province | |
| 20 km North West of Shanbeh, Bushehr Province | |
| 25 km South East of Buheyri, Bushehr Province | |
| 30 km South East of Khormog, Bushehr Province | |
| Depth | 30 km |
| Agency | |
Faults within 150 km: |
|
| BORAZJAN_F (Length: 168 km) , Distance to epicenter: 15 km | |
| MFF5 (Length: 74 km) , Distance to epicenter: 18 km | |
| MFF3 (Length: 292 km) , Distance to epicenter: 18 km | |
| Number of Phases | 5 |
| RMS | 0.1 |
| Number of Stations | 4 |
| Error in Latitude | >9 km |
| Error in Longitude | 5.5 km |
| Error in Depth | 3.8 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 88946 | IIEES | AHRM | N | 1810.1 | 0.56 | 2013-04-24 14:33:28 | 2013-04-24 03:56:00 | n |
| 88947 | IIEES | GHIR | N | 1567.7 | 0.52 | 2013-04-24 14:33:39 | 2013-04-24 03:56:00 | n |
| 88948 | IIEES | GHIR | E | 1512 | 0.52 | 2013-04-24 14:33:40 | 2013-04-24 03:56:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | AHRM | Z | Pg | E | 2013-04-24 14:33:06 | 0.01 | y | 53.5 | 332 | |||
| IIEES | GHIR | Z | Pg | E | 2013-04-24 14:33:20 | 0.06 | y | 141 | 97 | |||
| IIEES | GHIR | E | Sg | E | 2013-04-24 14:33:37 | -0.07 | y | 141 | 97 | |||
| IIEES | YZKH | Z | Pn | E | 2013-04-24 14:34:08 | 0.13 | y | 526 | 33 | |||
| IIEES | KHMZ | Z | Pn | E | 2013-04-24 14:34:18 | -0.17 | y | 607 | 346 | |||
