Event Specification
Magnitude |
2.9 |
| Date & Time (UTC) | 2013-09-27 03:37:07.2 |
| Date & Time (Local) | 1392/7/5 07:07:07.2 |
| Location | Lat:35.09 Lon: 53.4 |
| Region | Semnan Province, 53 km South of Semnan |
Nearest Cities |
|
| 45 km South East of Sorkheh, Semnan Province | |
| 45 km South East of Lasjerd, Semnan Province | |
| 50 km South of Alae, Semnan Province | |
| 53 km South of Semnan, Semnan Province | |
| 62 km South East of Aftar, Semnan Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| KUH_E_GUGERD_F (Length: 73 km) , Distance to epicenter: 8 km | |
| KUH_E_GACHAB_F2 (Length: 31 km) , Distance to epicenter: 21 km | |
| KUH_E_GACHAB_F1 (Length: 53 km) , Distance to epicenter: 31 km | |
| Number of Phases | 5 |
| RMS | 0.1 |
| Number of Stations | 3 |
| Error in Latitude | >2.1 km |
| Error in Longitude | 3.8 km |
| Error in Depth | 6.4 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 90645 | IIEES | GHVR | E | 112.1 | 0.48 | 2013-09-27 03:38:13 | 2013-09-27 06:35:00 | n |
| 90646 | IIEES | GHVR | N | 85.6 | 0.4 | 2013-09-27 03:38:14 | 2013-09-27 06:35:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | GHVR | Z | Pn | E | 2013-09-27 03:37:40 | 0.05 | y | 208 | 252 | |||
| IIEES | GHVR | N | Sg | E | 2013-09-27 03:38:06 | 0.01 | y | 208 | 252 | |||
| IIEES | CHTH | Z | Pn | E | 2013-09-27 03:37:43 | 0.08 | y | 225 | 294 | |||
| IIEES | CHTH | N | Sg | E | 2013-09-27 03:38:11 | -0.07 | y | 225 | 294 | |||
| IIEES | YZKH | Z | Pn | E | 2013-09-27 03:37:54 | -0.06 | y | 320 | 159 | |||
