Event Specification
Magnitude |
3.2 |
| Date & Time (UTC) | 2014-08-25 22:37:41.4 |
| Date & Time (Local) | 1393/6/4 03:07:41.4 |
| Location | Lat:32.78 Lon: 47.42 |
| Region | Ilam Province, 18 km South of Abdanan |
Nearest Cities |
|
| 17 km South of Abdanan, Ilam Province | |
| 18 km North East of Dehloran, Ilam Province | |
| 19 km South West of Sarabbagh, Ilam Province | |
| 27 km North of Musian, Ilam Province | |
| 40 km South East of Darreh Shahr, Ilam Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| MFF6 (Length: 144 km) , Distance to epicenter: 11 km | |
| BALARUD_F_Z1 (Length: 87 km) , Distance to epicenter: 32 km | |
| BALARUD_F_Z3 (Length: 53 km) , Distance to epicenter: 60 km | |
| Number of Phases | 7 |
| RMS | 0.2 |
| Number of Stations | 5 |
| Error in Latitude | >4.6 km |
| Error in Longitude | 8.7 km |
| Error in Depth | 5 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 93310 | IIEES | SHGR | N | 397.1 | 0.32 | 2014-08-25 22:38:28 | 2014-08-26 12:06:00 | n |
| 93311 | IIEES | SHGR | E | 463.9 | 0.44 | 2014-08-25 22:38:28 | 2014-08-26 12:06:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | SHGR | Z | Pg | E | 2014-08-25 22:38:06 | 0.17 | y | 150 | 119 | |||
| IIEES | SHGR | N | Sg | E | 2014-08-25 22:38:24 | -0.28 | y | 150 | 119 | |||
| IIEES | SNGE | Z | Pn | E | 2014-08-25 22:38:20 | -0.21 | y | 257 | 359 | |||
| IIEES | SNGE | N | Sg | E | 2014-08-25 22:38:53 | -0.11 | y | 257 | 359 | |||
| IIEES | KHMZ | Z | Pn | E | 2014-08-25 22:38:21 | -0.08 | y | 260 | 65 | |||
| IIEES | ASAO | Z | Pn | E | 2014-08-25 22:38:28 | 0.32 | y | 312 | 50 | |||
| IIEES | GHVR | Z | Pn | E | 2014-08-25 22:38:39 | 0.26 | y | 402 | 61 | |||
