Event Specification
Magnitude |
3 |
| Date & Time (UTC) | 2014-09-05 17:04:11.4 |
| Date & Time (Local) | 1393/6/14 21:34:11.4 |
| Location | Lat:32.75 Lon: 47.88 |
| Region | Ilam Province, 47 km South-East of Pol-e dokhtar |
Nearest Cities |
|
| 33 km West of Bidruyeh, Khoozestan Province | |
| 34 km South East of Sarabbagh, Ilam Province | |
| 35 km North West of Hoseinieh, Khoozestan Province | |
| 42 km West of Sorkhakan, Khoozestan Province | |
| 43 km South East of Sarab hammam, Lorestan Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| BALARUD_F_Z1 (Length: 87 km) , Distance to epicenter: 5 km | |
| BALARUD_F_Z3 (Length: 53 km) , Distance to epicenter: 19 km | |
| MFF6 (Length: 144 km) , Distance to epicenter: 28 km | |
| Number of Phases | 6 |
| RMS | 0.1 |
| Number of Stations | 5 |
| Error in Latitude | >1.4 km |
| Error in Longitude | 3.9 km |
| Error in Depth | 5.3 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 93484 | IIEES | AHRM | N | 11.3 | 0.56 | 2014-09-05 17:07:12 | 2014-09-05 07:18:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | SHGR | Z | Pg | E | 2014-09-05 17:04:30 | -0.16 | y | 113 | 129 | |||
| IIEES | SHGR | N | Sg | E | 2014-09-05 17:04:44 | 0.11 | y | 113 | 129 | |||
| IIEES | SNGE | Z | Pn | E | 2014-09-05 17:04:52 | 0.04 | y | 264 | 349 | |||
| IIEES | ASAO | Z | Pn | E | 2014-09-05 17:04:54 | 0.1 | y | 282 | 44 | |||
| IIEES | ASAO | E | Sg | E | 2014-09-05 17:05:30 | -0.03 | y | 282 | 44 | |||
| IIEES | GHVR | Z | Pn | E | 2014-09-05 17:05:04 | -0.07 | y | 366 | 58 | |||
