Event Specification
Magnitude |
3.2 |
| Date & Time (UTC) | 2016-05-25 00:58:04.2 |
| Date & Time (Local) | 1395/3/5 05:28:04.2 |
| Location | Lat:37.469 Lon: 57.471 |
| Region | Khorasan(north) Province, 12 km -East of Bojnurd |
Nearest Cities |
|
| 5 km of Hesar-egarmkhanh, Khorasan(north) Province | |
| 12 km East of Void, Khorasan(north) Province | |
| 12 km East of Bojnurd, Khorasan(north) Province | |
| 29 km North West of Zavarom, Khorasan(north) Province | |
| 33 km South West of Tukur, Khorasan(north) Province | |
| Depth | 16 km |
| Agency | |
Faults within 150 km: |
|
| ESFARAYEN_F (Length: 111 km) , Distance to epicenter: 37 km | |
| ROBATE_QARABIL_F (Length: 168 km) , Distance to epicenter: 43 km | |
| BAGHAN_GERMAB_F (Length: 79 km) , Distance to epicenter: 46 km | |
| Number of Phases | 8 |
| RMS | 0.2 |
| Number of Stations | 7 |
| Error in Latitude | >3.1 km |
| Error in Longitude | 4.8 km |
| Error in Depth | 5.9 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 106313 | IIEES | BJRD | E | 4248.7 | 0.4 | 2016-05-25 00:58:14 | 2016-05-25 05:23:00 | n |
| 106314 | IIEES | MRVT | E | 490.2 | 0.27 | 2016-05-25 00:58:47 | 2016-05-25 05:23:00 | n |
| 106315 | IIEES | MRVT | N | 383.3 | 0.39 | 2016-05-25 00:58:48 | 2016-05-25 05:23:00 | n |
| 106316 | IIEES | SHRO | N | 178.1 | 0.49 | 2016-05-25 00:59:04 | 2016-05-25 05:23:00 | n |
| 106317 | IIEES | SHRO | E | 215.6 | 0.54 | 2016-05-25 00:59:05 | 2016-05-25 05:23:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | BJRD | Z | Pg | E | 2016-05-25 00:58:09 | 0.06 | y | 26.2 | 348 | |||
| IIEES | MRVT | Z | Pg | E | 2016-05-25 00:58:24 | -0.12 | y | 124 | 280 | |||
| IIEES | SHRO | Z | Pn | E | 2016-05-25 00:58:37 | 0.33 | y | 208 | 219 | |||
| IIEES | SHRO | N | Sg | E | 2016-05-25 00:59:03 | 0.02 | y | 208 | 219 | |||
| IIEES | TABS | Z | Pn | E | 2016-05-25 00:59:04 | 0.09 | y | 425 | 184 | |||
| IIEES | SHRT | Z | Pn | E | 2016-05-25 00:59:13 | -0.02 | y | 495 | 148 | |||
| IIEES | YZKH | Z | Pn | E | 2016-05-25 00:59:28 | -0.58 | y | 622 | 206 | |||
| IIEES | BSRN | Z | Pn | E | 2016-05-25 00:59:29 | -0.08 | y | 629 | 166 | |||
