Event Specification
Magnitude |
3 |
| Date & Time (UTC) | 2016-07-29 07:08:16.3 |
| Date & Time (Local) | 1395/5/8 11:38:16.3 |
| Location | Lat:37.476 Lon: 57.448 |
| Region | Khorasan(north) Province, 10 km -East of Bojnurd |
Nearest Cities |
|
| 6 km of Hesar-egarmkhanh, Khorasan(north) Province | |
| 10 km North East of Void, Khorasan(north) Province | |
| 10 km North East of Bojnurd, Khorasan(north) Province | |
| 31 km North West of Zavarom, Khorasan(north) Province | |
| 35 km South West of Tukur, Khorasan(north) Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| ESFARAYEN_F (Length: 111 km) , Distance to epicenter: 37 km | |
| ROBATE_QARABIL_F (Length: 168 km) , Distance to epicenter: 42 km | |
| BAGHAN_GERMAB_F (Length: 79 km) , Distance to epicenter: 47 km | |
| Number of Phases | 9 |
| RMS | 0.3 |
| Number of Stations | 7 |
| Error in Latitude | >3.8 km |
| Error in Longitude | 6.3 km |
| Error in Depth | 7.9 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 108061 | IIEES | BJRD | E | 3091.1 | 0.22 | 2016-07-29 07:08:25 | 2016-07-31 07:49:00 | n |
| 108062 | IIEES | BJRD | N | 3169 | 0.24 | 2016-07-29 07:08:26 | 2016-07-31 07:49:00 | n |
| 108063 | IIEES | MRVT | E | 333.4 | 0.3 | 2016-07-29 07:08:58 | 2016-07-31 07:49:00 | n |
| 108064 | IIEES | MRVT | N | 348.8 | 0.25 | 2016-07-29 07:08:59 | 2016-07-31 07:49:00 | n |
| 108065 | IIEES | SHRO | N | 88.1 | 0.61 | 2016-07-29 07:09:18 | 2016-07-31 07:49:00 | n |
| 108066 | IIEES | TABS | N | 10.9 | 0.95 | 2016-07-29 07:10:26 | 2016-07-31 07:49:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | BJRD | Z | Pg | E | 2016-07-29 07:08:21 | -0.18 | y | 25.1 | 352 | |||
| IIEES | BJRD | N | Sg | E | 2016-07-29 07:08:25 | -0.13 | y | 25.1 | 352 | |||
| IIEES | MRVT | Z | Pg | E | 2016-07-29 07:08:37 | 0.29 | y | 122 | 280 | |||
| IIEES | SHRO | Z | Pn | E | 2016-07-29 07:08:50 | 0.46 | y | 207 | 219 | |||
| IIEES | SHRO | N | Sg | E | 2016-07-29 07:09:14 | -0.49 | y | 207 | 219 | |||
| IIEES | TABS | Z | Pn | E | 2016-07-29 07:09:17 | 0.21 | y | 426 | 184 | |||
| IIEES | SHRT | Z | Pn | E | 2016-07-29 07:09:25 | -0.24 | y | 497 | 148 | |||
| IIEES | YZKH | Z | Pn | E | 2016-07-29 07:09:41 | 0.03 | y | 621 | 206 | |||
| IIEES | BSRN | Z | Pn | E | 2016-07-29 07:09:42 | 0.07 | y | 630 | 165 | |||
