Event Specification
Magnitude |
3.6 |
| Date & Time (UTC) | 2016-08-17 04:25:41.5 |
| Date & Time (Local) | 1395/5/27 08:55:41.5 |
| Location | Lat:35.908 Lon: 53.207 |
| Region | Semnan Province, 27 km South-East of Pol-E-Sefid |
Nearest Cities |
|
| 5 km North of Chashem, Semnan Province | |
| 18 km South of Sangdeh, Mazandaran Province | |
| 19 km North West of Shahmirzad, Semnan Province | |
| 25 km South East of Shurmast-e peyrudbar, Mazandaran Province | |
| 25 km North West of Mehdishahr, Semnan Province | |
| Depth | 15 km |
| Agency | |
Faults within 150 km: |
|
| ATARI_F (Length: 185 km) , Distance to epicenter: 27 km | |
| N_ALBORZ_F (Length: 360 km) , Distance to epicenter: 33 km | |
| MOSHA_F (Length: 234 km) , Distance to epicenter: 56 km | |
| Number of Phases | 19 |
| RMS | 0.6 |
| Number of Stations | 18 |
| Error in Latitude | >5.9 km |
| Error in Longitude | 3.5 km |
| Error in Depth | 9 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 108607 | IIEES | GHVR | N | 501.6 | 0.51 | 2016-08-17 04:26:52 | 2016-08-17 05:01:00 | n |
| 108608 | IIEES | GHVR | E | 710.4 | 0.81 | 2016-08-17 04:26:52 | 2016-08-17 05:01:00 | n |
| 108609 | IIEES | GIDE | N | 179.4 | 0.39 | 2016-08-17 04:27:16 | 2016-08-17 05:01:00 | n |
| 108610 | IIEES | GIDE | E | 167 | 0.74 | 2016-08-17 04:27:18 | 2016-08-17 05:01:00 | n |
| 108611 | IIEES | ASAO | E | 81 | 0.78 | 2016-08-17 04:27:18 | 2016-08-17 05:01:00 | n |
| 108612 | IIEES | NASN | N | 83.4 | 0.43 | 2016-08-17 04:27:22 | 2016-08-17 05:01:00 | n |
| 108613 | IIEES | NASN | E | 137.5 | 0.71 | 2016-08-17 04:27:32 | 2016-08-17 05:01:00 | n |
| 108614 | IIEES | YZKH | N | 66.4 | 0.48 | 2016-08-17 04:27:48 | 2016-08-17 05:01:00 | n |
| 108615 | IIEES | YZKH | E | 50.6 | 0.48 | 2016-08-17 04:27:51 | 2016-08-17 05:01:00 | n |
| 108616 | IIEES | TABS | N | 58 | 0.57 | 2016-08-17 04:28:02 | 2016-08-17 05:01:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | DAMV | Z | Pg | E | 2016-08-17 04:26:00 | -0.93 | y | 116 | 255 | |||
| IIEES | CHTH | Z | Pg | E | 2016-08-17 04:26:12 | -0.5 | y | 188 | 271 | |||
| IIEES | GHVR | Z | Pn | E | 2016-08-17 04:26:18 | 0.01 | y | 239 | 229 | |||
| IIEES | SHRO | Z | Pn | E | 2016-08-17 04:26:20 | -0.01 | y | 253 | 87 | |||
| IIEES | SHRO | E | Sg | E | 2016-08-17 04:26:53 | 0.22 | y | 253 | 87 | |||
| IIEES | GIDE | Z | Pn | E | 2016-08-17 04:26:28 | -0.12 | y | 316 | 292 | |||
| IIEES | MRVT | Z | Pn | E | 2016-08-17 04:26:28 | -0.47 | y | 322 | 52 | |||
| IIEES | ASAO | Z | Pn | E | 2016-08-17 04:26:30 | 0.24 | y | 327 | 243 | |||
| IIEES | NASN | Z | Pn | E | 2016-08-17 04:26:32 | -0.08 | y | 347 | 186 | |||
| IIEES | KHMZ | Z | Pn | E | 2016-08-17 04:26:37 | 0.4 | y | 382 | 232 | |||
| IIEES | YZKH | Z | Pn | E | 2016-08-17 04:26:40 | -0.12 | y | 410 | 161 | |||
| IIEES | ZNJK | Z | Pn | E | 2016-08-17 04:26:42 | 1.65 | y | 415 | 283 | |||
| IIEES | BJRD | Z | Pn | E | 2016-08-17 04:26:42 | 0.21 | y | 424 | 61 | |||
| IIEES | TABS | Z | Pn | E | 2016-08-17 04:26:43 | 0.03 | y | 437 | 124 | |||
| IIEES | SNGE | Z | Pn | E | 2016-08-17 04:26:57 | 0.95 | y | 539 | 262 | |||
| IIEES | GRMI | Z | Pn | E | 2016-08-17 04:26:59 | -0.83 | y | 570 | 306 | |||
| IIEES | SHRT | Z | Pn | E | 2016-08-17 04:27:15 | 0.1 | y | 695 | 109 | |||
| IIEES | BSRN | Z | Pn | E | 2016-08-17 04:27:16 | 0.15 | y | 700 | 127 | |||
| IIEES | KRBR | Z | Pn | E | 2016-08-17 04:27:20 | -0.77 | y | 736 | 152 | |||
