Event Specification
Magnitude |
2.5 |
| Date & Time (UTC) | 2016-09-10 03:51:36.1 |
| Date & Time (Local) | 1395/6/20 08:21:36.1 |
| Location | Lat:36.835 Lon: 54.404 |
| Region | Golestan Province, 3 km of Gorgan |
Nearest Cities |
|
| 3 km of Gorgan, Golestan Province | |
| 6 km of Lamsak, Golestan Province | |
| 13 km West of Jalin olia, Golestan Province | |
| 19 km North of Naharkhoran, Golestan Province | |
| 20 km South of Aq Qaleh, Golestan Province | |
| Depth | 16 km |
| Agency | |
Faults within 150 km: |
|
| KHAZAR_F (Length: 523 km) , Distance to epicenter: 9 km | |
| N_ALBORZ_F (Length: 360 km) , Distance to epicenter: 25 km | |
| SHAVAR_F (Length: 87 km) , Distance to epicenter: 30 km | |
| Number of Phases | 10 |
| RMS | 0.3 |
| Number of Stations | 7 |
| Error in Latitude | >3.2 km |
| Error in Longitude | 2.4 km |
| Error in Depth | 5.8 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 109062 | IIEES | MRVT | N | 71.7 | 0.28 | 2016-09-10 03:52:30 | 2016-09-10 05:24:00 | n |
| 109063 | IIEES | MRVT | E | 76.1 | 0.36 | 2016-09-10 03:52:30 | 2016-09-10 05:24:00 | n |
| 109064 | IIEES | CHTH | E | 9.2 | 0.53 | 2016-09-10 03:53:08 | 2016-09-10 05:24:00 | n |
| 109065 | IIEES | CHTH | N | 13.5 | 0.99 | 2016-09-10 03:53:11 | 2016-09-10 05:24:00 | n |
| 109066 | IIEES | GHVR | E | 7.4 | 0.76 | 2016-09-10 03:53:44 | 2016-09-10 05:24:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | SHRO | Z | Pg | E | 2016-09-10 03:52:04 | 0.27 | y | 171 | 122 | |||
| IIEES | SHRO | N | Sg | E | 2016-09-10 03:52:24 | -0.29 | y | 171 | 122 | |||
| IIEES | MRVT | Z | Pg | E | 2016-09-10 03:52:05 | -0.04 | y | 175 | 58 | |||
| IIEES | MRVT | N | Sg | E | 2016-09-10 03:52:26 | 0.27 | y | 175 | 58 | |||
| IIEES | DAMV | Z | Pn | E | 2016-09-10 03:52:15 | -0.04 | y | 256 | 239 | |||
| IIEES | BJRD | Z | Pn | E | 2016-09-10 03:52:18 | -0.65 | y | 283 | 69 | |||
| IIEES | CHTH | Z | Pn | E | 2016-09-10 03:52:22 | 0.3 | y | 312 | 252 | |||
| IIEES | CHTH | N | Sg | E | 2016-09-10 03:53:03 | -0.24 | y | 312 | 252 | |||
| IIEES | GHVR | Z | Pn | E | 2016-09-10 03:52:31 | 0.09 | y | 387 | 229 | |||
| IIEES | TABS | Z | Pn | E | 2016-09-10 03:52:37 | 0.41 | y | 431 | 144 | |||
