Event Specification
Magnitude |
2.5 |
| Date & Time (UTC) | 2016-12-23 22:31:27.3 |
| Date & Time (Local) | 1395/10/4 02:01:27.3 |
| Location | Lat:36.425 Lon: 54.583 |
| Region | Semnan Province, 34 km -West of Shahrud |
Nearest Cities |
|
| 8 km of Majen, Semnan Province | |
| 18 km South East of Cheharbagh, Golestan Province | |
| 23 km North of Mehmandust, Semnan Province | |
| 30 km South East of Naharkhoran, Golestan Province | |
| 34 km North West of Shahrud, Semnan Province | |
| Depth | 15 km |
| Agency | |
Faults within 150 km: |
|
| ASTANEH_F (Length: 72 km) , Distance to epicenter: 7 km | |
| DAMGHAN_F (Length: 95 km) , Distance to epicenter: 18 km | |
| ATARI_F (Length: 185 km) , Distance to epicenter: 20 km | |
| Number of Phases | 12 |
| RMS | 0.4 |
| Number of Stations | 12 |
| Error in Latitude | >5.2 km |
| Error in Longitude | 5.1 km |
| Error in Depth | 8.7 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 111701 | IIEES | MRVT | E | 39.2 | 0.25 | 2016-12-23 22:32:29 | 2016-12-24 05:52:00 | n |
| 111702 | IIEES | DAMV | E | 32.9 | 0.56 | 2016-12-23 22:32:43 | 2016-12-24 05:52:00 | n |
| 111703 | IIEES | BJRD | N | 13.9 | 0.51 | 2016-12-23 22:32:57 | 2016-12-24 05:52:00 | n |
| 111704 | IIEES | BJRD | E | 14.9 | 0.45 | 2016-12-23 22:33:01 | 2016-12-24 05:52:00 | n |
| 111705 | IIEES | GHVR | N | 13.8 | 0.25 | 2016-12-23 22:33:16 | 2016-12-24 05:52:00 | n |
| 111706 | IIEES | GHVR | E | 13.8 | 0.42 | 2016-12-23 22:33:17 | 2016-12-24 05:52:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | SHRO | Z | Pg | E | 2016-12-23 22:31:50 | 0.14 | y | 137 | 109 | |||
| IIEES | MRVT | Z | Pg | E | 2016-12-23 22:31:58 | -0.47 | y | 192 | 44 | |||
| IIEES | DAMV | Z | Pn | E | 2016-12-23 22:32:06 | -0.32 | y | 251 | 250 | |||
| IIEES | BJRD | Z | Pn | E | 2016-12-23 22:32:11 | 0.4 | y | 288 | 60 | |||
| IIEES | CHTH | Z | Pn | E | 2016-12-23 22:32:14 | 0.36 | y | 316 | 261 | |||
| IIEES | GHVR | Z | Pn | E | 2016-12-23 22:32:21 | 0.52 | y | 372 | 236 | |||
| IIEES | TABS | Z | Pn | E | 2016-12-23 22:32:23 | 0.24 | y | 385 | 142 | |||
| IIEES | NASN | Z | Pn | E | 2016-12-23 22:32:27 | -1.08 | y | 434 | 203 | |||
| IIEES | YZKH | Z | Pn | E | 2016-12-23 22:32:30 | 0.15 | y | 448 | 180 | |||
| IIEES | ASAO | Z | Pn | E | 2016-12-23 22:32:32 | 0.27 | y | 463 | 245 | |||
| IIEES | KHMZ | Z | Pn | E | 2016-12-23 22:32:38 | -0.18 | y | 516 | 236 | |||
| IIEES | SHRT | Z | Pn | E | 2016-12-23 22:32:49 | -0.11 | y | 605 | 119 | |||
