Event Specification
Magnitude |
3 |
| Date & Time (UTC) | 2017-03-01 10:19:44.1 |
| Date & Time (Local) | 1395/12/11 13:49:44.1 |
| Location | Lat:36.793 Lon: 54.439 |
| Region | Golestan Province, 5 km of Gorgan |
Nearest Cities |
|
| 5 km of Gorgan, Golestan Province | |
| 11 km East of Lamsak, Golestan Province | |
| 11 km West of Jalin olia, Golestan Province | |
| 14 km North of Naharkhoran, Golestan Province | |
| 24 km South West of Nodeh malek, Golestan Province | |
| Depth | 15 km |
| Agency | |
Faults within 150 km: |
|
| KHAZAR_F (Length: 523 km) , Distance to epicenter: 9 km | |
| N_ALBORZ_F (Length: 360 km) , Distance to epicenter: 21 km | |
| SHAVAR_F (Length: 87 km) , Distance to epicenter: 25 km | |
| Number of Phases | 14 |
| RMS | 0.3 |
| Number of Stations | 13 |
| Error in Latitude | >4 km |
| Error in Longitude | 4.1 km |
| Error in Depth | 9.6 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 113665 | IIEES | MRVT | N | 215.1 | 0.31 | 2017-03-01 10:20:39 | 2017-03-01 10:52:00 | n |
| 113666 | IIEES | MRVT | E | 172 | 0.37 | 2017-03-01 10:20:40 | 2017-03-01 10:52:00 | n |
| 113667 | IIEES | DAMV | N | 78 | 0.24 | 2017-03-01 10:20:51 | 2017-03-01 10:52:00 | n |
| 113668 | IIEES | DAMV | E | 116.8 | 0.48 | 2017-03-01 10:20:53 | 2017-03-01 10:52:00 | n |
| 113669 | IIEES | BJRD | E | 64 | 0.24 | 2017-03-01 10:21:15 | 2017-03-01 10:52:00 | n |
| 113670 | IIEES | BJRD | N | 45.5 | 0.47 | 2017-03-01 10:21:21 | 2017-03-01 10:52:00 | n |
| 113671 | IIEES | CHTH | N | 33.3 | 0.44 | 2017-03-01 10:21:10 | 2017-03-01 10:52:00 | n |
| 113672 | IIEES | CHTH | E | 25.7 | 0.44 | 2017-03-01 10:21:14 | 2017-03-01 10:52:00 | n |
| 113673 | IIEES | THKV | N | 76.3 | 0.35 | 2017-03-01 10:21:17 | 2017-03-01 10:52:00 | n |
| 113674 | IIEES | THKV | E | 80.7 | 0.49 | 2017-03-01 10:21:21 | 2017-03-01 10:52:00 | n |
| 113675 | IIEES | GHVR | N | 9.9 | 0.31 | 2017-03-01 10:21:40 | 2017-03-01 10:52:00 | n |
| 113676 | IIEES | GHVR | E | 28 | 0.72 | 2017-03-01 10:21:44 | 2017-03-01 10:52:00 | n |
| 113677 | IIEES | ASAO | N | 6.2 | 0.71 | 2017-03-01 10:22:15 | 2017-03-01 10:52:00 | n |
| 113678 | IIEES | ZNJK | N | 6.5 | 0.48 | 2017-03-01 10:22:09 | 2017-03-01 10:52:00 | n |
| 113679 | IIEES | GRMI | N | 4.6 | 0.15 | 2017-03-01 10:22:21 | 2017-03-01 10:52:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | SHRO | Z | Pg | E | 2017-03-01 10:20:12 | 0.45 | y | 166 | 121 | |||
| IIEES | MRVT | Z | Pg | E | 2017-03-01 10:20:12 | -0.32 | y | 175 | 56 | |||
| IIEES | DAMV | Z | Pn | E | 2017-03-01 10:20:17 | -5.81 | n | 4 | 257 | 241 | ||
| IIEES | BJRD | Z | Pn | E | 2017-03-01 10:20:26 | -0.19 | y | 282 | 68 | |||
| IIEES | BJRD | E | Sg | E | 2017-03-01 10:21:03 | 0.13 | y | 282 | 68 | |||
| IIEES | CHTH | Z | Pn | E | 2017-03-01 10:20:31 | 0.23 | y | 313 | 253 | |||
| IIEES | THKV | Z | Pn | E | 2017-03-01 10:20:33 | 0.53 | y | 334 | 254 | |||
| IIEES | GHVR | Z | Pn | E | 2017-03-01 10:20:39 | 0.09 | y | 387 | 229 | |||
| IIEES | TABS | Z | Pn | E | 2017-03-01 10:20:44 | 0.11 | y | 426 | 144 | |||
| IIEES | NASN | Z | Pn | E | 2017-03-01 10:20:49 | -0.53 | y | 467 | 199 | |||
| IIEES | ASAO | Z | Pn | E | 2017-03-01 10:20:49 | -0.45 | y | 471 | 239 | |||
| IIEES | YZKH | Z | Pn | E | 2017-03-01 10:20:52 | -0.29 | y | 489 | 178 | |||
| IIEES | ZNJK | Z | Pn | E | 2017-03-01 10:20:55 | -0.36 | y | 514 | 270 | |||
| IIEES | GRMI | Z | Pn | E | 2017-03-01 10:21:08 | 0.4 | y | 618 | 293 | |||
