Event Specification
Magnitude |
3.2 |
| Date & Time (UTC) | 2017-08-16 13:42:17.4 |
| Date & Time (Local) | 1396/5/25 18:12:17.4 |
| Location | Lat:27.343 Lon: 57.37 |
| Region | Kerman Province, 14 km -West of Manujan |
Nearest Cities |
|
| 14 km West of Manujan, Kerman Province | |
| 16 km East of Dehbarez, Hormozgan Province | |
| 19 km East of Balashahr, Hormozgan Province | |
| 23 km South of Nodezh, Kerman Province | |
| 30 km South of Bejogan, Kerman Province | |
| Depth | 23 km |
| Agency | |
Faults within 150 km: |
|
| ZENDAN_MINAB_F_Z1 (Length: 183 km) , Distance to epicenter: 19 km | |
| SABZEVARAN_F (Length: 190 km) , Distance to epicenter: 19 km | |
| MAIN_ZAGROS_R_F (Length: 1106 km) , Distance to epicenter: 23 km | |
| Number of Phases | 7 |
| RMS | 0.2 |
| Number of Stations | 4 |
| Error in Latitude | >6.4 km |
| Error in Longitude | 4.9 km |
| Error in Depth | 8.4 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 118755 | IIEES | BNDS | E | 1185.8 | 0.37 | 2017-08-16 13:42:53 | 2017-08-21 08:59:00 | n |
| 118756 | IIEES | BNDS | N | 780.1 | 0.41 | 2017-08-16 13:42:54 | 2017-08-21 08:59:00 | n |
| 118757 | IIEES | KRBR | N | 69.5 | 0.33 | 2017-08-16 13:43:41 | 2017-08-21 08:59:00 | n |
| 118758 | IIEES | KRBR | E | 81 | 0.27 | 2017-08-16 13:43:42 | 2017-08-21 08:59:00 | n |
| 118759 | IIEES | GHIR | E | 14.6 | 0.4 | 2017-08-16 13:44:16 | 2017-08-21 08:59:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | BNDS | Z | Pg | E | 2017-08-16 13:42:37 | 0.17 | y | 119 | 273 | |||
| IIEES | BNDS | N | Sg | E | 2017-08-16 13:42:51 | -0.12 | y | 119 | 273 | |||
| IIEES | KRBR | Z | Pn | E | 2017-08-16 13:43:01 | 0.09 | y | 298 | 349 | |||
| IIEES | KRBR | N | S | E | 2017-08-16 13:43:33 | 0.09 | y | 298 | 349 | |||
| IIEES | GHIR | Z | Pn | E | 2017-08-16 13:43:19 | -0.02 | y | 444 | 285 | |||
| IIEES | BSRN | Z | Pn | E | 2017-08-16 13:43:38 | 7.45 | n | 4 | 540 | 18 | ||
| IIEES | TABS | Z | Pn | E | 2017-08-16 13:43:50 | -0.47 | y | 700 | 358 | |||
