Event Specification
Magnitude |
3.8 |
| Date & Time (UTC) | 2017-11-14 06:51:13.8 |
| Date & Time (Local) | 1396/8/23 10:21:13.8 |
| Location | Lat:33.887 Lon: 47.621 |
| Region | Lorestan Province, 40 km North of Kuhdasht |
Nearest Cities |
|
| 23 km South of Kahrizvardasht-e olia, Lorestan Province | |
| 33 km South West of Zafarabad, Lorestan Province | |
| 37 km West of Farhadabad, Lorestan Province | |
| 38 km South West of Haftcheshmeh, Lorestan Province | |
| 38 km South West of Nurabad, Lorestan Province | |
| Depth | 15 km |
| Agency | |
Faults within 150 km: |
|
| HZF4 (Length: 492 km) , Distance to epicenter: 1 km | |
| SAHANEH_F (Length: 77 km) , Distance to epicenter: 63 km | |
| DINEHVAR_F (Length: 46 km) , Distance to epicenter: 68 km | |
| Number of Phases | 18 |
| RMS | 0.4 |
| Number of Stations | 16 |
| Error in Latitude | >3.2 km |
| Error in Longitude | 5.2 km |
| Error in Depth | 9 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 121552 | IIEES | SNGE | E | 770.9 | 0.51 | 2017-11-14 06:52:02 | 2017-11-14 07:17:00 | n |
| 121553 | IIEES | SNGE | N | 806.8 | 0.61 | 2017-11-14 06:52:02 | 2017-11-14 07:17:00 | n |
| 121554 | IIEES | KHMZ | E | 667.9 | 0.7 | 2017-11-14 06:52:23 | 2017-11-14 07:17:00 | n |
| 121555 | IIEES | KHMZ | N | 922.5 | 0.87 | 2017-11-14 06:52:31 | 2017-11-14 07:17:00 | n |
| 121556 | IIEES | ASAO | E | 420.2 | 0.66 | 2017-11-14 06:52:27 | 2017-11-14 07:17:00 | n |
| 121557 | IIEES | ASAO | N | 613.9 | 0.44 | 2017-11-14 06:52:30 | 2017-11-14 07:17:00 | n |
| 121558 | IIEES | GHVR | E | 377.9 | 0.74 | 2017-11-14 06:53:03 | 2017-11-14 07:17:00 | n |
| 121559 | IIEES | GHVR | N | 396.2 | 0.84 | 2017-11-14 06:53:09 | 2017-11-14 07:17:00 | n |
| 121560 | IIEES | GIDE | N | 139 | 0.86 | 2017-11-14 06:53:19 | 2017-11-14 07:17:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | ILBA | Z | Pg | E | 2017-11-14 06:51:36 | -0.05 | y | 134 | 258 | |||
| IIEES | ILBA | N | Sg | E | 2017-11-14 06:51:52 | 0.03 | y | 134 | 258 | |||
| IIEES | SNGE | Z | Pg | E | 2017-11-14 06:51:36 | -0.34 | y | 136 | 349 | |||
| IIEES | SNGE | E | Sg | E | 2017-11-14 06:51:53 | -0.21 | y | 136 | 349 | |||
| IIEES | KHMZ | Z | Pn | E | 2017-11-14 06:51:48 | -0.27 | y | 218 | 94 | |||
| IIEES | ASAO | Z | Pn | E | 2017-11-14 06:51:50 | -0.33 | y | 233 | 71 | |||
| IIEES | ZNJK | Z | Pn | E | 2017-11-14 06:52:02 | 0.35 | y | 324 | 17 | |||
| IIEES | GHVR | Z | Pn | E | 2017-11-14 06:52:04 | 1.17 | y | 340 | 78 | |||
| IIEES | THKV | Z | Pn | E | 2017-11-14 06:52:07 | 0.05 | y | 373 | 52 | |||
| IIEES | CHTH | Z | Pn | E | 2017-11-14 06:52:10 | -0.12 | y | 391 | 54 | |||
| IIEES | GIDE | Z | Pn | E | 2017-11-14 06:52:11 | 0.44 | y | 396 | 31 | |||
| IIEES | DAMV | Z | Pn | E | 2017-11-14 06:52:16 | -0.37 | y | 443 | 63 | |||
| IIEES | NASN | Z | Pn | E | 2017-11-14 06:52:23 | -0.04 | y | 498 | 103 | |||
| IIEES | GRMI | Z | Pn | E | 2017-11-14 06:52:29 | 0.09 | y | 547 | 2 | |||
| IIEES | AHRM | Z | Pn | E | 2017-11-14 06:52:43 | 0.12 | y | 657 | 147 | |||
| IIEES | MAKU | Z | Pn | E | 2017-11-14 06:52:44 | 0.43 | y | 661 | 337 | |||
| IIEES | YZKH | Z | Pn | E | 2017-11-14 06:52:43 | -1.09 | y | 671 | 102 | |||
| IIEES | SHRO | Z | Pn | E | 2017-11-14 06:53:01 | 0.09 | y | 802 | 71 | |||
