Event Specification
Magnitude |
3.3 |
| Date & Time (UTC) | 2017-11-22 03:43:33.5 |
| Date & Time (Local) | 1396/9/1 07:13:33.5 |
| Location | Lat:34.771 Lon: 45.75 |
| Region | Kermanshah Province, 8 km of Tazehabad |
Nearest Cities |
|
| 3 km North of Tappeh rash, Kermanshah Province | |
| 8 km North of Tazehabad, Kermanshah Province | |
| 8 km North of Gardehnu, Kermanshah Province | |
| 22 km North West of Bazmirabad, Kermanshah Province | |
| 22 km West of Dehsheykh, Kermanshah Province | |
| Depth | 15 km |
| Agency | |
Faults within 150 km: |
|
| MFF8 (Length: 48 km) , Distance to epicenter: 9 km | |
| HZF4 (Length: 492 km) , Distance to epicenter: 32 km | |
| PIRANSHAHR_F (Length: 253 km) , Distance to epicenter: 86 km | |
| Number of Phases | 10 |
| RMS | 0.4 |
| Number of Stations | 9 |
| Error in Latitude | >4.6 km |
| Error in Longitude | 6.1 km |
| Error in Depth | 6.4 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 122291 | IIEES | ILBA | N | 582.6 | 0.32 | 2017-11-22 03:44:18 | 2017-11-22 06:25:00 | n |
| 122292 | IIEES | SNGE | N | 516.1 | 0.6 | 2017-11-22 03:44:24 | 2017-11-22 06:25:00 | n |
| 122293 | IIEES | SNGE | E | 394.9 | 0.43 | 2017-11-22 03:44:24 | 2017-11-22 06:25:00 | n |
| 122294 | IIEES | ASAO | E | 35 | 0.79 | 2017-11-22 03:45:32 | 2017-11-22 06:25:00 | n |
| 122295 | IIEES | KHMZ | E | 31.9 | 0.33 | 2017-11-22 03:45:39 | 2017-11-22 06:25:00 | n |
| 122296 | IIEES | KHMZ | N | 39.9 | 0.78 | 2017-11-22 03:45:46 | 2017-11-22 06:25:00 | n |
| 122297 | IIEES | GIDE | E | 29.4 | 0.62 | 2017-11-22 03:45:47 | 2017-11-22 06:25:00 | n |
| 122298 | IIEES | GIDE | N | 45.2 | 0.62 | 2017-11-22 03:46:14 | 2017-11-22 06:25:00 | n |
| 122299 | IIEES | GHVR | E | 19.5 | 0.5 | 2017-11-22 03:46:04 | 2017-11-22 06:25:00 | n |
| 122300 | IIEES | GHVR | N | 16.1 | 0.62 | 2017-11-22 03:46:13 | 2017-11-22 06:25:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | ILBA | Z | Pg | E | 2017-11-22 03:43:55 | -0.11 | y | 134 | 162 | |||
| IIEES | SNGE | Z | Pg | E | 2017-11-22 03:43:57 | -0.71 | y | 150 | 76 | |||
| IIEES | SNGE | N | Sg | E | 2017-11-22 03:44:16 | 0.05 | y | 150 | 76 | |||
| IIEES | ZNJK | Z | Pn | E | 2017-11-22 03:44:23 | 0.07 | y | 339 | 51 | |||
| IIEES | ASAO | Z | Pn | E | 2017-11-22 03:44:30 | 0.35 | y | 393 | 92 | |||
| IIEES | KHMZ | Z | Pn | E | 2017-11-22 03:44:31 | -0.08 | y | 405 | 105 | |||
| IIEES | GIDE | Z | Pn | E | 2017-11-22 03:44:36 | 0.39 | y | 445 | 56 | |||
| IIEES | GHVR | Z | Pn | E | 2017-11-22 03:44:44 | 0.72 | y | 505 | 92 | |||
| IIEES | MAKU | Z | Pn | E | 2017-11-22 03:44:45 | -0.13 | y | 517 | 350 | |||
| IIEES | DAMV | Z | Pn | E | 2017-11-22 03:44:52 | -0.32 | y | 574 | 79 | |||
