Event Specification
Magnitude |
4.2 |
| Date & Time (UTC) | 2017-11-23 22:30:51.2 |
| Date & Time (Local) | 1396/9/3 02:00:51.2 |
| Location | Lat:33.821 Lon: 48.756 |
| Region | Lorestan Province, 8 km of Borujerd |
Nearest Cities |
|
| 4 km of Hemmatabad, Lorestan Province | |
| 8 km of Borujerd, Lorestan Province | |
| 9 km of Valanjerd, Lorestan Province | |
| 12 km North East of Pellekan-e sofla, Lorestan Province | |
| 18 km South of Bon dizeh, Lorestan Province | |
| Depth | 15 km |
| Agency | |
Faults within 150 km: |
|
| NAHAVAND_F (Length: 102 km) , Distance to epicenter: 2 km | |
| DORUD (Length: 100 km) , Distance to epicenter: 2 km | |
| MAIN_ZAGROS_R_F (Length: 1106 km) , Distance to epicenter: 47 km | |
| Number of Phases | 24 |
| RMS | 1 |
| Number of Stations | 22 |
| Error in Latitude | >8.4 km |
| Error in Longitude | 6 km |
| Error in Depth | 9.9 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 122403 | IIEES | KHMZ | N | 4156.9 | 0.67 | 2017-11-23 22:31:28 | 2017-11-25 06:12:00 | n |
| 122404 | IIEES | ASAO | E | 3316.8 | 0.25 | 2017-11-23 22:31:32 | 2017-11-25 06:12:00 | n |
| 122405 | IIEES | ASAO | N | 4705 | 0.51 | 2017-11-23 22:31:35 | 2017-11-25 06:12:00 | n |
| 122406 | IIEES | SNGE | N | 1605.2 | 0.36 | 2017-11-23 22:31:50 | 2017-11-25 06:12:00 | n |
| 122407 | IIEES | GHVR | E | 1830.4 | 0.51 | 2017-11-23 22:32:02 | 2017-11-25 06:12:00 | n |
| 122408 | IIEES | GHVR | N | 1981.1 | 0.6 | 2017-11-23 22:32:08 | 2017-11-25 06:12:00 | n |
| 122409 | IIEES | THKV | N | 712.1 | 0.63 | 2017-11-23 22:32:17 | 2017-11-25 06:12:00 | n |
| 122410 | IIEES | THKV | E | 876.1 | 0.58 | 2017-11-23 22:32:19 | 2017-11-25 06:12:00 | n |
| 122411 | IIEES | DAMV | E | 291.5 | 0.58 | 2017-11-23 22:32:42 | 2017-11-25 06:12:00 | n |
| 122412 | IIEES | GIDE | N | 324.6 | 0.64 | 2017-11-23 22:32:41 | 2017-11-25 06:12:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | KHMZ | Z | Pg | E | 2017-11-23 22:31:09 | -1.08 | y | 112 | 94 | |||
| IIEES | ASAO | Z | Pg | E | 2017-11-23 22:31:13 | -1.39 | y | 142 | 55 | |||
| IIEES | ASAO | N | Sg | E | 2017-11-23 22:31:30 | -1.45 | y | 142 | 55 | |||
| IIEES | SNGE | Z | Pg | E | 2017-11-23 22:31:20 | -2.12 | y | 191 | 318 | |||
| IIEES | SNGE | E | Sg | E | 2017-11-23 22:31:45 | 0.11 | y | 191 | 318 | |||
| IIEES | ILBA | Z | Pn | E | 2017-11-23 22:31:28 | -0.21 | y | 237 | 265 | |||
| IIEES | GHVR | Z | Pn | E | 2017-11-23 22:31:29 | 0.65 | y | 241 | 72 | |||
| IIEES | THKV | Z | Pn | E | 2017-11-23 22:31:37 | 0.98 | y | 303 | 39 | |||
| IIEES | ZNJK | Z | Pn | E | 2017-11-23 22:31:38 | 0.52 | y | 316 | 359 | |||
| IIEES | CHTH | Z | Pn | E | 2017-11-23 22:31:39 | 0.88 | y | 317 | 42 | |||
| IIEES | DAMV | Z | Pn | E | 2017-11-23 22:31:44 | 0.75 | y | 356 | 55 | |||
| IIEES | GIDE | Z | Pn | E | 2017-11-23 22:31:44 | 0.84 | y | 360 | 17 | |||
| IIEES | NASN | Z | Pn | E | 2017-11-23 22:31:48 | 0.79 | y | 394 | 106 | |||
| IIEES | GRMI | Z | Pn | E | 2017-11-23 22:32:09 | 0.73 | y | 559 | 352 | |||
| IIEES | YZKH | Z | Pn | E | 2017-11-23 22:32:09 | 0.49 | y | 567 | 105 | |||
| IIEES | SHRO | Z | Pn | E | 2017-11-23 22:32:26 | 0.16 | y | 706 | 68 | |||
| IIEES | MAKU | Z | Pn | E | 2017-11-23 22:32:28 | 0.8 | y | 714 | 331 | |||
| IIEES | GHIR | Z | Pn | E | 2017-11-23 22:32:28 | -1.18 | y | 734 | 146 | |||
| IIEES | TABS | Z | Pn | E | 2017-11-23 22:32:36 | 1.58 | y | 775 | 89 | |||
| IIEES | MRVT | Z | Pn | E | 2017-11-23 22:32:37 | 0.78 | y | 788 | 55 | |||
| IIEES | KRBR | Z | Pn | E | 2017-11-23 22:32:46 | -0.12 | y | 868 | 117 | |||
| IIEES | BJRD | Z | Pn | E | 2017-11-23 22:32:50 | 0.79 | y | 893 | 59 | |||
| IIEES | BSRN | Z | Pn | E | 2017-11-23 22:33:01 | -0.07 | y | 991 | 99 | |||
| IIEES | BNDS | Z | Pn | E | 2017-11-23 22:33:02 | -1.8 | y | 1005 | 133 | |||
