Event Specification
Magnitude |
3.5 |
| Date & Time (UTC) | 2017-12-24 06:52:24.4 |
| Date & Time (Local) | 1396/10/3 10:22:24.4 |
| Location | Lat:34.923 Lon: 45.879 |
| Region | Kermanshah Province, 18 km North of Tazehabad |
Nearest Cities |
|
| 12 km North of Dehsheykh, Kermanshah Province | |
| 17 km South of Markhil, Kermanshah Province | |
| 18 km North of Tazehabad, Kermanshah Province | |
| 21 km West of Bayangan, Kermanshah Province | |
| 23 km West of Mazran, Kermanshah Province | |
| Depth | 15 km |
| Agency | |
Faults within 150 km: |
|
| HZF4 (Length: 492 km) , Distance to epicenter: 14 km | |
| MFF8 (Length: 48 km) , Distance to epicenter: 29 km | |
| PIRANSHAHR_F (Length: 253 km) , Distance to epicenter: 65 km | |
| Number of Phases | 13 |
| RMS | 0.4 |
| Number of Stations | 11 |
| Error in Latitude | >4.2 km |
| Error in Longitude | 6.7 km |
| Error in Depth | 9.5 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 125301 | IIEES | SNGE | E | 698.2 | 0.5 | 2017-12-24 06:53:09 | 2017-12-24 08:14:00 | n |
| 125302 | IIEES | SNGE | N | 859.5 | 0.81 | 2017-12-24 06:53:10 | 2017-12-24 08:14:00 | n |
| 125303 | IIEES | ILBA | N | 873.6 | 0.61 | 2017-12-24 06:53:11 | 2017-12-24 08:14:00 | n |
| 125304 | IIEES | KHMZ | E | 42.6 | 0.78 | 2017-12-24 06:54:25 | 2017-12-24 08:14:00 | n |
| 125305 | IIEES | KHMZ | N | 48.2 | 0.39 | 2017-12-24 06:54:29 | 2017-12-24 08:14:00 | n |
| 125306 | IIEES | GIDE | N | 77.9 | 0.8 | 2017-12-24 06:54:37 | 2017-12-24 08:14:00 | n |
| 125307 | IIEES | GHVR | N | 51.5 | 0.82 | 2017-12-24 06:54:57 | 2017-12-24 08:14:00 | n |
| 125308 | IIEES | GHVR | E | 26.5 | 0.55 | 2017-12-24 06:55:10 | 2017-12-24 08:14:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | SNGE | Z | Pg | E | 2017-12-24 06:52:46 | -0.56 | y | 135 | 82 | |||
| IIEES | SNGE | N | Sg | E | 2017-12-24 06:53:03 | 0.18 | y | 135 | 82 | |||
| IIEES | ILBA | Z | Pg | E | 2017-12-24 06:52:47 | -0.94 | y | 147 | 168 | |||
| IIEES | ILBA | N | Sg | E | 2017-12-24 06:53:07 | 0.65 | y | 147 | 168 | |||
| IIEES | ZNJK | Z | Pn | E | 2017-12-24 06:53:11 | -0.06 | y | 319 | 52 | |||
| IIEES | ASAO | Z | Pn | E | 2017-12-24 06:53:20 | 0.48 | y | 382 | 95 | |||
| IIEES | KHMZ | Z | Pn | E | 2017-12-24 06:53:21 | 0.09 | y | 398 | 108 | |||
| IIEES | GIDE | Z | Pn | E | 2017-12-24 06:53:24 | -0.36 | y | 426 | 57 | |||
| IIEES | GRMI | Z | Pn | E | 2017-12-24 06:53:30 | 0.33 | y | 467 | 22 | |||
| IIEES | CHTH | Z | Pn | E | 2017-12-24 06:53:33 | 0.15 | y | 489 | 76 | |||
| IIEES | GHVR | Z | Pn | E | 2017-12-24 06:53:33 | 0.07 | y | 494 | 94 | |||
| IIEES | MAKU | Z | Pn | E | 2017-12-24 06:53:35 | 0.37 | y | 503 | 348 | |||
| IIEES | DAMV | Z | Pn | E | 2017-12-24 06:53:41 | -0.14 | y | 560 | 80 | |||
