Event Specification
Magnitude |
3.1 |
| Date & Time (UTC) | 2018-01-13 00:50:18.1 |
| Date & Time (Local) | 1396/10/23 04:20:18.1 |
| Location | Lat:38.505 Lon: 45.378 |
| Region | Azarbaijan Sharghi Province, 35 km -West of Marand |
Nearest Cities |
|
| 17 km North West of Kashksaray, Azarbaijan Sharghi Province | |
| 18 km South of Yekan kahriz, Azarbaijan Sharghi Province | |
| 20 km North of Jahregan, Azarbaijan Sharghi Province | |
| 22 km North of Tasuj, Azarbaijan Sharghi Province | |
| 22 km West of Yamchi, Azarbaijan Sharghi Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| N_TABRIZ_F1 (Length: 222 km) , Distance to epicenter: 8 km | |
| N_TABRIZ_F3 (Length: 66 km) , Distance to epicenter: 16 km | |
| N_TABRIZ_F2 (Length: 52 km) , Distance to epicenter: 36 km | |
| Number of Phases | 6 |
| RMS | 0.4 |
| Number of Stations | 4 |
| Error in Latitude | >5.3 km |
| Error in Longitude | 5.3 km |
| Error in Depth | 9.5 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 126669 | IIEES | MAKU | E | 447 | 0.33 | 2018-01-13 00:50:56 | 2018-01-13 07:54:00 | n |
| 126670 | IIEES | GRMI | E | 145.6 | 0.41 | 2018-01-13 00:51:25 | 2018-01-13 07:54:00 | n |
| 126671 | IIEES | GRMI | N | 146.6 | 0.47 | 2018-01-13 00:51:27 | 2018-01-13 07:54:00 | n |
| 126672 | IIEES | SNGE | E | 14.8 | 0.58 | 2018-01-13 00:52:24 | 2018-01-13 07:54:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | MAKU | Z | Pg | E | 2018-01-13 00:50:36 | -0.36 | y | 112 | 328 | |||
| IIEES | GRMI | Z | Pn | E | 2018-01-13 00:50:54 | 0.65 | y | 222 | 80 | |||
| IIEES | GRMI | N | Sg | E | 2018-01-13 00:51:20 | -0.13 | y | 222 | 80 | |||
| IIEES | ZNJK | Z | Pn | E | 2018-01-13 00:51:10 | 0.18 | y | 356 | 124 | |||
| IIEES | ZNJK | N | Sg | E | 2018-01-13 00:51:57 | -0.5 | y | 356 | 124 | |||
| IIEES | SNGE | Z | Pn | E | 2018-01-13 00:51:17 | 0.15 | y | 417 | 155 | |||
