Event Specification
Magnitude |
2.9 |
| Date & Time (UTC) | 2018-02-25 13:02:27.6 |
| Date & Time (Local) | 1396/12/6 16:32:27.6 |
| Location | Lat:39.648 Lon: 45.094 |
| Region | Azerbaijan, 56 km North-West of Nakhicevan |
Nearest Cities |
|
| 33 km North of Paldasht, Azarbaijan Gharbi Province | |
| 40 km East of Qush, Azarbaijan Gharbi Province | |
| 42 km North East of Eshqabad, Azarbaijan Gharbi Province | |
| 49 km North East of Yolakaldi, Azarbaijan Gharbi Province | |
| 50 km North of Bohlulabad, Azarbaijan Gharbi Province | |
| Depth | 15 km |
| Agency | |
Faults within 150 km: |
|
| KHOY (Length: 100 km) , Distance to epicenter: 72 km | |
| N_TABRIZ_F1 (Length: 222 km) , Distance to epicenter: 135 km | |
| N_TABRIZ_F3 (Length: 66 km) , Distance to epicenter: 144 km | |
| Number of Phases | 7 |
| RMS | 0.1 |
| Number of Stations | 4 |
| Error in Latitude | >4.7 km |
| Error in Longitude | 1.9 km |
| Error in Depth | 2.9 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 128996 | IIEES | MAKU | E | 1026.3 | 0.21 | 2018-02-25 13:02:46 | 2018-02-27 07:25:00 | n |
| 128997 | IIEES | MAKU | N | 1192.2 | 0.12 | 2018-02-25 13:02:47 | 2018-02-27 07:25:00 | n |
| 128998 | IIEES | GRMI | E | 64.8 | 0.58 | 2018-02-25 13:03:42 | 2018-02-27 07:25:00 | n |
| 128999 | IIEES | GRMI | N | 76.7 | 0.54 | 2018-02-25 13:03:43 | 2018-02-27 07:25:00 | n |
| 129000 | IIEES | ZNJK | E | 6.8 | 0.58 | 2018-02-25 13:04:46 | 2018-02-27 07:25:00 | n |
| 129001 | IIEES | ZNJK | N | 7.2 | 0.58 | 2018-02-25 13:04:47 | 2018-02-27 07:25:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | MAKU | Z | Pg | E | 2018-02-25 13:02:36 | -0.23 | y | 48 | 227 | |||
| IIEES | MAKU | N | Sg | E | 2018-02-25 13:02:43 | 0.17 | y | 48 | 227 | |||
| IIEES | GRMI | Z | Pn | E | 2018-02-25 13:03:07 | 0.16 | y | 259 | 110 | |||
| IIEES | GRMI | N | Sg | E | 2018-02-25 13:03:40 | 0.01 | y | 259 | 110 | |||
| IIEES | SRSL | Z | Pn | E | 2018-02-25 13:03:22 | 0.02 | y | 382 | 175 | |||
| IIEES | ZNJK | Z | Pn | E | 2018-02-25 13:03:32 | -0.05 | y | 456 | 135 | |||
| IIEES | ZNJK | N | S | E | 2018-02-25 13:04:19 | -0.11 | y | 456 | 135 | |||
