Event Specification
Magnitude |
3.3 |
| Date & Time (UTC) | 2018-07-24 07:37:40.8 |
| Date & Time (Local) | 1397/5/2 12:07:40.8 |
| Location | Lat:34.607 Lon: 46.284 |
| Region | Kermanshah Province, 29 km South-West of Javanrud |
Nearest Cities |
|
| 9 km of Mirabad, Kermanshah Province | |
| 12 km North of Zavleh olia, Kermanshah Province | |
| 17 km South East of Qolqoleh, Kermanshah Province | |
| 19 km West of Dolatabad, Kermanshah Province | |
| 23 km South West of Sarukhan, Kermanshah Province | |
| Depth | 6 km |
| Agency | |
Faults within 150 km: |
|
| HZF4 (Length: 492 km) , Distance to epicenter: 12 km | |
| MFF8 (Length: 48 km) , Distance to epicenter: 34 km | |
| SARTAKHT_F (Length: 78 km) , Distance to epicenter: 60 km | |
| Number of Phases | 11 |
| RMS | 0.2 |
| Number of Stations | 9 |
| Error in Latitude | >2.7 km |
| Error in Longitude | 5 km |
| Error in Depth | 3.9 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 135075 | IIEES | ILBA | N | 874.1 | 0.37 | 2018-07-24 07:38:22 | 2018-07-24 09:36:00 | n |
| 135076 | IIEES | ILBA | E | 736.9 | 0.37 | 2018-07-24 07:38:24 | 2018-07-24 09:36:00 | n |
| 135077 | IIEES | SNGE | E | 633.4 | 0.28 | 2018-07-24 07:38:17 | 2018-07-24 09:36:00 | n |
| 135078 | IIEES | SNGE | N | 703.8 | 0.52 | 2018-07-24 07:38:18 | 2018-07-24 09:36:00 | n |
| 135079 | IIEES | GHVR | E | 37.6 | 0.35 | 2018-07-24 07:40:06 | 2018-07-24 09:36:00 | n |
| 135080 | IIEES | GHVR | N | 20.2 | 0.44 | 2018-07-24 07:40:08 | 2018-07-24 09:36:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | ILBA | Z | Pg | E | 2018-07-24 07:37:59 | -0.4 | y | 109 | 184 | |||
| IIEES | ILBA | N | Sg | E | 2018-07-24 07:38:13 | 0.17 | y | 109 | 184 | |||
| IIEES | SNGE | Z | Pg | E | 2018-07-24 07:38:00 | -0.15 | y | 111 | 61 | |||
| IIEES | SNGE | N | Sg | E | 2018-07-24 07:38:14 | -0.08 | y | 111 | 61 | |||
| IIEES | ZNJK | Z | Pn | E | 2018-07-24 07:38:29 | 0.25 | y | 316 | 43 | |||
| IIEES | ASAO | Z | Pn | E | 2018-07-24 07:38:32 | 0.1 | y | 343 | 90 | |||
| IIEES | KHMZ | Z | Pn | E | 2018-07-24 07:38:33 | 0.33 | y | 353 | 105 | |||
| IIEES | THKV | Z | Pn | E | 2018-07-24 07:38:44 | -0.16 | y | 443 | 70 | |||
| IIEES | GHVR | Z | Pn | E | 2018-07-24 07:38:46 | 0.16 | y | 456 | 90 | |||
| IIEES | CHTH | Z | Pn | E | 2018-07-24 07:38:46 | -0.34 | y | 464 | 70 | |||
| IIEES | GRMI | Z | Pn | E | 2018-07-24 07:38:50 | 0.13 | y | 488 | 17 | |||
