Event Specification
Magnitude |
2.5 |
| Date & Time (UTC) | 2018-07-27 01:21:36.1 |
| Date & Time (Local) | 1397/5/5 05:51:36.1 |
| Location | Lat:34.63 Lon: 46.272 |
| Region | Kermanshah Province, 28 km South-West of Javanrud |
Nearest Cities |
|
| 7 km of Mirabad, Kermanshah Province | |
| 14 km East of Qolqoleh, Kermanshah Province | |
| 15 km North of Zavleh olia, Kermanshah Province | |
| 19 km West of Dolatabad, Kermanshah Province | |
| 22 km South West of Sarukhan, Kermanshah Province | |
| Depth | 6 km |
| Agency | |
Faults within 150 km: |
|
| HZF4 (Length: 492 km) , Distance to epicenter: 14 km | |
| MFF8 (Length: 48 km) , Distance to epicenter: 35 km | |
| SARTAKHT_F (Length: 78 km) , Distance to epicenter: 59 km | |
| Number of Phases | 7 |
| RMS | 0.2 |
| Number of Stations | 5 |
| Error in Latitude | >3.6 km |
| Error in Longitude | 6.9 km |
| Error in Depth | 4.6 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 135206 | IIEES | SNGE | E | 120.6 | 0.32 | 2018-07-27 01:22:12 | 2018-07-28 08:15:00 | n |
| 135207 | IIEES | SNGE | N | 141.6 | 0.44 | 2018-07-27 01:22:13 | 2018-07-28 08:15:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | SNGE | Z | Pg | E | 2018-07-27 01:21:55 | -0.44 | y | 111 | 62 | |||
| IIEES | SNGE | N | Sg | E | 2018-07-27 01:22:09 | 0.16 | y | 111 | 62 | |||
| IIEES | ILBA | Z | Pg | E | 2018-07-27 01:21:55 | 0.11 | y | 112 | 183 | |||
| IIEES | ILBA | E | Sg | E | 2018-07-27 01:22:09 | -0.08 | y | 112 | 183 | |||
| IIEES | ZNJK | Z | Pn | E | 2018-07-27 01:22:24 | 0.17 | y | 315 | 43 | |||
| IIEES | ASAO | Z | Pn | E | 2018-07-27 01:22:27 | -0.09 | y | 344 | 90 | |||
| IIEES | KHMZ | Z | Pn | E | 2018-07-27 01:22:29 | 0.21 | y | 354 | 105 | |||
