Event Specification
Magnitude |
3.5 |
| Date & Time (UTC) | 2020-07-12 00:45:36.1 |
| Date & Time (Local) | 1399/4/22 05:15:36.1 |
| Location | Lat:35.67 Lon: 52.54 |
| Region | Tehran Province, 22 km -West of Firuzkuh |
Nearest Cities |
|
| 12 km North of Atashan, Tehran Province | |
| 15 km South of Arjomand, Tehran Province | |
| 20 km South West of Shahrabad, Tehran Province | |
| 21 km North East of Sarbandan, Tehran Province | |
| 22 km West of Firuzkuh, Tehran Province | |
| Depth | 10 km |
| Agency | |
Faults within 150 km: |
|
| MOSHA_F (Length: 234 km) , Distance to epicenter: 9 km | |
| ATARI_F (Length: 185 km) , Distance to epicenter: 38 km | |
| GARMSAR_F (Length: 77 km) , Distance to epicenter: 42 km | |
| Number of Phases | 21 |
| RMS | 0.9 |
| Number of Stations | 21 |
| Error in Latitude | >4 km |
| Error in Longitude | 0 km |
| Error in Depth | 0 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 155455 | IIEES SC | DAMV | Z | 1600 | 1 | 2020-07-12 00:45:50 | 2020-07-12 11:28:00 | n |
| 155456 | IIEES SC | CHTH | Z | 1.4 | 1 | 2020-07-12 00:46:29 | 2020-07-12 11:28:00 | n |
| 155457 | IIEES SC | THKV | Z | 540 | 1 | 2020-07-12 00:46:25 | 2020-07-12 11:28:00 | n |
| 155458 | IIEES SC | GHVR | Z | 710 | 1 | 2020-07-12 00:46:13 | 2020-07-12 11:28:00 | n |
| 155459 | IIEES SC | ASAO | Z | 340 | 1 | 2020-07-12 00:46:52 | 2020-07-12 11:28:00 | n |
| 155460 | IIEES SC | SHRO | Z | 2.9 | 1 | 2020-07-12 00:46:59 | 2020-07-12 11:28:00 | n |
| 155461 | IIEES SC | KHMZ | Z | 110 | 1 | 2020-07-12 00:47:09 | 2020-07-12 11:28:00 | n |
| 155462 | IIEES SC | NASN | Z | 89 | 1 | 2020-07-12 00:46:54 | 2020-07-12 11:28:00 | n |
| 155463 | IIEES SC | ZNJK | Z | 48 | 1 | 2020-07-12 00:47:12 | 2020-07-12 11:28:00 | n |
| 155464 | IIEES SC | MRVT | Z | 59 | 1 | 2020-07-12 00:47:29 | 2020-07-12 11:28:00 | n |
| 155465 | IIEES SC | YZKH | Z | 89 | 1 | 2020-07-12 00:47:40 | 2020-07-12 11:28:00 | n |
| 155466 | IIEES SC | GTMR | Z | 46 | 1 | 2020-07-12 00:48:00 | 2020-07-12 11:28:00 | n |
| 155467 | IIEES SC | SNGE | Z | 46 | 1 | 2020-07-12 00:48:00 | 2020-07-12 11:28:00 | n |
| 155468 | IIEES SC | GRMI | Z | 18 | 1 | 2020-07-12 00:47:56 | 2020-07-12 11:28:00 | n |
| 155469 | IIEES SC | ILBA | Z | 11 | 1 | 2020-07-12 00:48:51 | 2020-07-12 11:28:00 | n |
| 155470 | IIEES SC | KAGH | Z | 5.5 | 1 | 2020-07-12 00:49:12 | 2020-07-12 11:28:00 | n |
| 155471 | IIEES SC | BSRN | Z | 19 | 1 | 2020-07-12 00:49:16 | 2020-07-12 11:28:00 | n |
| 155472 | IIEES SC | SHRT | Z | 19 | 1 | 2020-07-12 00:49:25 | 2020-07-12 11:28:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES SC | DAMV | Z | IP | I | 2020-07-12 00:45:44 | -1.9 | y | 55 | 266 | |||
| IIEES SC | DAMV | Z | IS | I | 2020-07-12 00:45:52 | -0.9 | y | 55 | 266 | |||
| IIEES SC | CHTH | Z | IP | I | 2020-07-12 00:45:56 | -1.2 | y | 133 | 282 | |||
| IIEES SC | GLO | Z | IP | I | 2020-07-12 00:45:59 | -0.9 | y | 144 | 51 | |||
| IIEES SC | THKV | Z | IP | I | 2020-07-12 00:46:01 | 0.2 | y | 155 | 281 | |||
| IIEES SC | GHVR | Z | IP | I | 2020-07-12 00:46:04 | 0 | y | 177 | 222 | |||
| IIEES SC | ASAO | Z | IP | I | 2020-07-12 00:46:15 | 0.4 | y | 255 | 242 | |||
| IIEES SC | SHRO | Z | IP | I | 2020-07-12 00:46:21 | -0.1 | y | 311 | 82 | |||
| IIEES SC | KHMZ | Z | IP | I | 2020-07-12 00:46:23 | 1.4 | y | 322 | 229 | |||
| IIEES SC | NASN | Z | IP | I | 2020-07-12 00:46:22 | 0.2 | y | 322 | 176 | |||
| IIEES SC | ZNJK | Z | IP | I | 2020-07-12 00:46:28 | 0.6 | y | 366 | 289 | |||
| IIEES SC | MRVT | Z | IP | I | 2020-07-12 00:46:30 | 0.5 | y | 389 | 54 | |||
| IIEES SC | YZKH | Z | IP | I | 2020-07-12 00:46:31 | -1.1 | y | 411 | 152 | |||
| IIEES SC | TABS | Z | IP | I | 2020-07-12 00:46:40 | -0.8 | y | 478 | 117 | |||
| IIEES SC | GTMR | Z | IP | I | 2020-07-12 00:46:42 | 1.7 | y | 478 | 223 | |||
| IIEES SC | SNGE | Z | IP | I | 2020-07-12 00:46:42 | 0.9 | y | 478 | 264 | |||
| IIEES SC | GRMI | Z | IP | I | 2020-07-12 00:46:50 | 0.9 | y | 544 | 312 | |||
| IIEES SC | ILBA | N | IP | I | 2020-07-12 00:46:58 | -0.6 | y | 622 | 251 | |||
| IIEES SC | KAGH | Z | IP | I | 2020-07-12 00:47:07 | 1.1 | y | 678 | 76 | |||
| IIEES SC | BSRN | Z | IP | I | 2020-07-12 00:47:12 | -0.4 | y | 733 | 122 | |||
| IIEES SC | SHRT | Z | IP | I | 2020-07-12 00:47:14 | -0.1 | y | 745 | 105 | |||
