Event Specification
Magnitude |
3.4 |
| Date & Time (UTC) | 2022-09-24 18:40:08.5 |
| Date & Time (Local) | 1401/7/2 22:10:08.5 |
| Location | Lat:32.008 Lon: 49.895 |
| Region | Khoozestan Province, 19 km North of Izeh |
Nearest Cities |
|
| 7 km North of Torshak, Khoozestan Province | |
| 18 km North of Rasvand, Khoozestan Province | |
| 19 km North of Izeh, Khoozestan Province | |
| 27 km North East of Chenarestan, Khoozestan Province | |
| 42 km North of Ghaleh tal, Khoozestan Province | |
| Depth | 12 km |
| Agency | |
Faults within 150 km: |
|
| MFF2 (Length: 205 km) , Distance to epicenter: 12 km | |
| ZARDKUH_F (Length: 139 km) , Distance to epicenter: 31 km | |
| DOPOLAN_F (Length: 107 km) , Distance to epicenter: 33 km | |
| Number of Phases | 19 |
| RMS | 0.4 |
| Number of Stations | 19 |
| Error in Latitude | >1.4 km |
| Error in Longitude | 1.4 km |
| Error in Depth | 7 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 173703 | IIEES SC | GTMR | Z | 2 | 1 | 2022-09-24 18:40:23 | 2022-09-26 04:40:00 | n |
| 173704 | IIEES SC | KHMZ | Z | 0.5 | 1 | 2022-09-24 18:40:40 | 2022-09-26 04:40:00 | n |
| 173705 | IIEES SC | KLNJ | Z | 0.8 | 1 | 2022-09-24 18:40:40 | 2022-09-26 04:40:00 | n |
| 173706 | IIEES SC | ASAO | Z | 0.3 | 1 | 2022-09-24 18:40:51 | 2022-09-26 04:40:00 | n |
| 173707 | IIEES SC | NASN | Z | 0.1 | 1 | 2022-09-24 18:40:52 | 2022-09-26 04:40:00 | n |
| 173708 | IIEES SC | GHVR | Z | 0.2 | 1 | 2022-09-24 18:40:54 | 2022-09-26 04:40:00 | n |
| 173709 | IIEES SC | ILBA | Z | 0.08 | 1 | 2022-09-24 18:41:04 | 2022-09-26 04:40:00 | n |
| 173710 | IIEES SC | SNGE | Z | 0.09 | 1 | 2022-09-24 18:41:08 | 2022-09-26 04:40:00 | n |
| 173711 | IIEES SC | YZKH | Z | 0.04 | 1 | 2022-09-24 18:41:11 | 2022-09-26 04:40:00 | n |
| 173712 | IIEES SC | DAMV | Z | 0.06 | 1 | 2022-09-24 18:41:11 | 2022-09-26 04:40:00 | n |
| 173713 | IIEES SC | CHTH | Z | 0.04 | 1 | 2022-09-24 18:41:11 | 2022-09-26 04:40:00 | n |
| 173714 | IIEES SC | ABGH | Z | 0.03 | 1 | 2022-09-24 18:41:42 | 2022-09-26 04:40:00 | n |
| 173715 | IIEES SC | TABS | Z | 0.02 | 1 | 2022-09-24 18:41:42 | 2022-09-26 04:40:00 | n |
| 173716 | IIEES SC | KKHK | Z | 0.02 | 1 | 2022-09-24 18:42:01 | 2022-09-26 04:40:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES SC | GTMR | Z | EPg | E | 2022-09-24 18:40:23 | -0.5 | y | 0 | 90 | 305 | ||
| IIEES SC | AHWZ | Z | EPg | E | 2022-09-24 18:40:31 | 0 | y | 0 | 140 | 238 | ||
| IIEES SC | KHMZ | Z | EPg | E | 2022-09-24 18:40:40 | 0.3 | y | 0 | 192 | 2 | ||
| IIEES SC | KLNJ | Z | EPg | E | 2022-09-24 18:40:40 | 0.1 | y | 0 | 196 | 125 | ||
| IIEES SC | ASAO | Z | EPn | E | 2022-09-24 18:40:51 | -0.2 | y | 0 | 282 | 2 | ||
| IIEES SC | NASN | Z | EPn | E | 2022-09-24 18:40:52 | 0 | y | 0 | 288 | 72 | ||
| IIEES SC | GHVR | Z | EPn | E | 2022-09-24 18:40:54 | 0.8 | y | 0 | 302 | 25 | ||
| IIEES SC | KCHF | Z | EPn | E | 2022-09-24 18:41:01 | -0.8 | y | 0 | 366 | 313 | ||
| IIEES SC | ILBA | Z | EPn | E | 2022-09-24 18:41:04 | 0.1 | y | 0 | 389 | 297 | ||
| IIEES SC | HGHA | Z | EPn | E | 2022-09-24 18:41:06 | 0.6 | y | 0 | 398 | 346 | ||
| IIEES SC | SNGE | Z | EPn | E | 2022-09-24 18:41:08 | 0.7 | y | 0 | 416 | 325 | ||
| IIEES SC | YZKH | Z | EPn | E | 2022-09-24 18:41:11 | -0.4 | y | 0 | 445 | 85 | ||
| IIEES SC | DAMV | Z | EPn | E | 2022-09-24 18:41:11 | -0.7 | y | 0 | 445 | 26 | ||
| IIEES SC | CHTH | Z | EPn | E | 2022-09-24 18:41:11 | -0.9 | y | 0 | 447 | 15 | ||
| IIEES SC | ABGH | Z | EPn | E | 2022-09-24 18:41:42 | -0.1 | y | 0 | 692 | 41 | ||
| IIEES SC | TABS | Z | EPn | E | 2022-09-24 18:41:42 | -0.8 | y | 0 | 700 | 75 | ||
| IIEES SC | SHRO | Z | EPn | E | 2022-09-24 18:41:27 | -18.7 | n | 4 | 718 | 52 | ||
| IIEES SC | KKHK | Z | EPn | E | 2022-09-24 18:42:01 | -0.9 | y | 0 | 850 | 74 | ||
| IIEES SC | RAYN | Z | EPn | E | 2022-09-24 18:42:17 | -7.2 | n | 4 | 1035 | 205 | ||
