Event Specification
Magnitude |
3.5 |
| Date & Time (UTC) | 2007-12-01 18:22:17.8 |
| Date & Time (Local) | 1386/9/10 21:52:17.8 |
| Location | Lat:38.22 Lon: 46.48 |
| Region | 23 km North-East of Tabriz, Azarbaijan Sharghi Province |
Nearest Cities |
|
| 11 km North West of Khvajeh, Azarbaijan Sharghi Province | |
| 13 km East of Yangi esperan, Azarbaijan Sharghi Province | |
| 14 km West of Sarand, Azarbaijan Sharghi Province | |
| 23 km North East of Tabriz, Azarbaijan Sharghi Province | |
| 25 km North of Basmanj, Azarbaijan Sharghi Province | |
| Depth | 15 km |
| Agency | |
Faults within 150 km: |
|
| N_TABRIZ_F1 (Length: 222 km) , Distance to epicenter: 20 km | |
| N_TABRIZ_F2 (Length: 52 km) , Distance to epicenter: 44 km | |
| BOZQUSH (Length: 70 km) , Distance to epicenter: 83 km | |
| Number of Phases | 8 |
| RMS | 0.2 |
| Number of Stations | 5 |
| Error in Latitude | >1.7 km |
| Error in Longitude | 1.9 km |
| Error in Depth | 4.9 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 40352 | IIEES | GRMI | N | 995.9 | 0.47 | 2007-12-01 18:23:02 | 2008-04-12 10:47:00 | n |
| 40353 | IIEES | MAKU | N | 504.9 | 0.45 | 2007-12-01 18:23:18 | 2008-04-12 10:47:00 | n |
| 40354 | IIEES | ZNJK | N | 229.2 | 0.48 | 2007-12-01 18:23:33 | 2008-04-12 10:47:00 | n |
| 40355 | IIEES | SNGE | N | 139.3 | 0.53 | 2007-12-01 18:24:01 | 2008-04-12 10:47:00 | n |
| 40356 | IIEES | SNGE | E | 146 | 0.14 | 2007-12-01 18:24:03 | 2008-04-12 10:47:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | GRMI | Z | Pg | E | 2007-12-01 18:22:41 | -0.1 | y | 140 | 61 | |||
| IIEES | GRMI | N | Sg | E | 2007-12-01 18:22:58 | 0.1 | y | 140 | 61 | |||
| IIEES | MAKU | Z | Pg | E | 2007-12-01 18:22:50 | -0.1 | y | 201 | 309 | |||
| IIEES | MAKU | E | Sg | E | 2007-12-01 18:23:15 | 0.1 | y | 201 | 309 | |||
| IIEES | ZNJK | Z | Pn | E | 2007-12-01 18:22:57 | -0.3 | y | 260 | 131 | |||
| IIEES | SNGE | Z | Pn | E | 2007-12-01 18:23:09 | 0.1 | y | 355 | 167 | |||
| IIEES | SNGE | E | Sg | E | 2007-12-01 18:23:57 | 0 | y | 355 | 167 | |||
| IIEES | CHTH | Z | Pn | E | 2007-12-01 18:23:26 | 0.3 | y | 486 | 120 | |||
