Event Specification
Magnitude |
3.5 |
| Date & Time (UTC) | 2008-03-17 20:49:35.9 |
| Date & Time (Local) | 1386/12/28 00:19:35.9 |
| Location | Lat:32.88 Lon: 47.41 |
| Region | 7 km Abdanan, Ilam Province |
Nearest Cities |
|
| 8 km of Abdanan, Ilam Province | |
| 15 km West of Sarabbagh, Ilam Province | |
| 25 km North East of Dehloran, Ilam Province | |
| 29 km South East of Darreh Shahr, Ilam Province | |
| 33 km South of Dashtabad-e olia, Ilam Province | |
| Depth | 42 km |
| Agency | |
Faults within 150 km: |
|
| MFF6 (Length: 144 km) , Distance to epicenter: 21 km | |
| BALARUD_F_Z1 (Length: 87 km) , Distance to epicenter: 22 km | |
| BALARUD_F_Z3 (Length: 53 km) , Distance to epicenter: 60 km | |
| Number of Phases | 7 |
| RMS | 0.1 |
| Number of Stations | 5 |
| Error in Latitude | >2.3 km |
| Error in Longitude | 4.6 km |
| Error in Depth | 4.4 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 48599 | IIEES | SHGR | E | 1021.8 | 0.72 | 2008-03-17 20:50:24 | 2008-12-28 01:25:00 | n |
| 48600 | IIEES | SHGR | N | 463.3 | 0.48 | 2008-03-17 20:50:42 | 2008-12-28 01:25:00 | n |
| 48601 | IIEES | SNGE | E | 312 | 0.64 | 2008-03-17 20:50:47 | 2008-12-28 01:25:00 | n |
| 48602 | IIEES | ASAO | E | 132 | 0.64 | 2008-03-17 20:51:03 | 2008-12-28 01:25:00 | n |
| 48603 | IIEES | ASAO | N | 166.4 | 0.68 | 2008-03-17 20:51:06 | 2008-12-28 01:25:00 | n |
| 48604 | IIEES | RMKL | N | 249 | 0.52 | 2008-03-17 20:51:16 | 2008-12-28 01:25:00 | n |
| 48605 | IIEES | RMKL | E | 139.6 | 0.48 | 2008-03-17 20:51:18 | 2008-12-28 01:25:00 | n |
| 48606 | IIEES | GHVR | E | 72 | 0.64 | 2008-03-17 20:51:25 | 2008-12-28 01:25:00 | n |
| 48607 | IIEES | GHVR | N | 63.2 | 0.64 | 2008-03-17 20:51:38 | 2008-12-28 01:25:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | SHGR | Z | Pg | E | 2008-03-17 20:50:01 | 0 | y | 156 | 123 | |||
| IIEES | SNGE | Z | Pn | E | 2008-03-17 20:50:11 | 0.1 | y | 246 | 359 | |||
| IIEES | SNGE | E | Sg | E | 2008-03-17 20:50:44 | 0 | y | 246 | 359 | |||
| IIEES | ASAO | Z | Pn | E | 2008-03-17 20:50:18 | -0.3 | y | 305 | 52 | |||
| IIEES | ASAO | N | Sg | E | 2008-03-17 20:51:00 | 0 | y | 305 | 52 | |||
| IIEES | RMKL | Z | Pn | E | 2008-03-17 20:50:19 | -0.1 | y | 309 | 132 | |||
| IIEES | GHVR | Z | Pn | E | 2008-03-17 20:50:30 | 0.3 | y | 397 | 62 | |||
