Event Specification
Magnitude |
3.6 |
| Date & Time (UTC) | 2012-04-25 13:39:52.5 |
| Date & Time (Local) | 1391/2/6 18:09:52.5 |
| Location | Lat:32.66 Lon: 47.23 |
| Region | Ilam Province, 5 km Dehloran |
Nearest Cities |
|
| 5 km of Dehloran, Ilam Province | |
| 18 km North West of Musian, Ilam Province | |
| 30 km South East of Bishehzar, Ilam Province | |
| 37 km South West of Abdanan, Ilam Province | |
| 41 km South West of Sarabbagh, Ilam Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| MFF6 (Length: 144 km) , Distance to epicenter: 10 km | |
| BALARUD_F_Z1 (Length: 87 km) , Distance to epicenter: 44 km | |
| BALARUD_F_Z3 (Length: 53 km) , Distance to epicenter: 80 km | |
| Number of Phases | 6 |
| RMS | 0.1 |
| Number of Stations | 5 |
| Error in Latitude | >4 km |
| Error in Longitude | 6.9 km |
| Error in Depth | 7.7 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 83082 | IIEES | SHGR | N | 1286.9 | 0.48 | 2012-04-25 13:40:45 | 2012-04-25 01:53:00 | n |
| 83083 | IIEES | SHGR | E | 1201.5 | 0.32 | 2012-04-25 13:40:45 | 2012-04-25 01:53:00 | n |
| 83084 | IIEES | SNGE | N | 223.6 | 0.48 | 2012-04-25 13:41:17 | 2012-04-25 01:53:00 | n |
| 83085 | IIEES | SNGE | E | 295.8 | 0.64 | 2012-04-25 13:41:24 | 2012-04-25 01:53:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | SHGR | Z | Pn | E | 2012-04-25 13:40:19 | -0.11 | y | 160 | 112 | |||
| IIEES | SNGE | Z | Pn | E | 2012-04-25 13:40:33 | 0.05 | y | 270 | 2 | |||
| IIEES | SNGE | E | Sg | E | 2012-04-25 13:41:08 | -0.09 | y | 270 | 2 | |||
| IIEES | KHMZ | Z | Pn | E | 2012-04-25 13:40:35 | -0.01 | y | 282 | 64 | |||
| IIEES | ASAO | Z | Pn | E | 2012-04-25 13:40:42 | 0.14 | y | 334 | 50 | |||
| IIEES | CHTH | Z | Pn | E | 2012-04-25 13:41:03 | 0.04 | y | 509 | 44 | |||
