Event Specification
Magnitude |
3.4 |
| Date & Time (UTC) | 2012-06-10 04:18:12.5 |
| Date & Time (Local) | 1391/3/21 08:48:12.5 |
| Location | Lat:33.77 Lon: 56.75 |
| Region | Yazd Province, 25 km North-West of Tabas |
Nearest Cities |
|
| 6 km North of Jokhvah, Yazd Province | |
| 25 km North West of Tabas, Yazd Province | |
| 28 km North West of Oshtoqran, Yazd Province | |
| 39 km North West of Kerit, Yazd Province | |
| 47 km West of Reqqeh, Khorasan(center) Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| TABAS_F1 (Length: 91 km) , Distance to epicenter: 13 km | |
| NAINI_F (Length: 342 km) , Distance to epicenter: 26 km | |
| TABAS_F2 (Length: 67 km) , Distance to epicenter: 26 km | |
| Number of Phases | 6 |
| RMS | 0.2 |
| Number of Stations | 5 |
| Error in Latitude | >2.1 km |
| Error in Longitude | 4.3 km |
| Error in Depth | 5.8 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 84090 | IIEES | NASN | N | 69 | 0.36 | 2012-06-10 04:19:52 | 2012-06-10 05:06:00 | n |
| 84091 | IIEES | NASN | E | 41.7 | 0.32 | 2012-06-10 04:19:54 | 2012-06-10 05:06:00 | n |
| 84092 | IIEES | KRBR | E | 82.8 | 0.29 | 2012-06-10 04:20:04 | 2012-06-10 05:06:00 | n |
| 84093 | IIEES | KRBR | N | 78.9 | 0.52 | 2012-06-10 04:20:06 | 2012-06-10 05:06:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | TABS | Z | Pg | E | 2012-06-10 04:18:19 | 0.06 | y | 36.9 | 111 | |||
| IIEES | SHRO | Z | Pn | E | 2012-06-10 04:18:52 | -0.02 | y | 258 | 345 | |||
| IIEES | SHRO | E | Sg | E | 2012-06-10 04:19:25 | -0.13 | y | 258 | 345 | |||
| IIEES | NASN | Z | Pn | E | 2012-06-10 04:19:08 | 0.17 | y | 382 | 255 | |||
| IIEES | KRBR | Z | Pn | E | 2012-06-10 04:19:12 | -0.27 | y | 420 | 180 | |||
| IIEES | MRVT | Z | Pn | E | 2012-06-10 04:19:14 | 0.2 | y | 436 | 352 | |||
