Event Specification
Magnitude |
2.3 |
| Date & Time (UTC) | 2012-08-29 08:36:33.5 |
| Date & Time (Local) | 1391/6/8 13:06:33.5 |
| Location | Lat:38.41 Lon: 46.78 |
| Region | Azarbaijan Sharghi Province, 27 km West of Ahar |
Nearest Cities |
|
| 15 km East of Varzagan, Azarbaijan Sharghi Province | |
| 19 km North West of Nikcheh, Azarbaijan Sharghi Province | |
| 19 km South of Tokhmdel, Azarbaijan Sharghi Province | |
| 19 km North East of Sarand, Azarbaijan Sharghi Province | |
| 21 km North of Bilverdi, Azarbaijan Sharghi Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| N_TABRIZ_F1 (Length: 222 km) , Distance to epicenter: 48 km | |
| N_TABRIZ_F2 (Length: 52 km) , Distance to epicenter: 72 km | |
| BOZQUSH (Length: 70 km) , Distance to epicenter: 80 km | |
| Number of Phases | 4 |
| RMS | 0.1 |
| Number of Stations | 3 |
| Error in Latitude | >5 km |
| Error in Longitude | 2.5 km |
| Error in Depth | 6.6 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 85846 | IIEES | GRMI | N | 76.3 | 0.24 | 2012-08-29 08:37:06 | 2012-08-29 10:52:00 | n |
| 85847 | IIEES | MAKU | N | 24.1 | 0.44 | 2012-08-29 08:37:36 | 2012-08-29 10:52:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | GRMI | Z | Pg | E | 2012-08-29 08:36:51 | -0.01 | y | 106 | 65 | |||
| IIEES | MAKU | Z | Pn | E | 2012-08-29 08:37:07 | 0.12 | y | 210 | 301 | |||
| IIEES | MAKU | N | Sg | E | 2012-08-29 08:37:33 | -0.07 | y | 210 | 301 | |||
| IIEES | ZNJK | Z | Pn | E | 2012-08-29 08:37:13 | -0.04 | y | 256 | 138 | |||
