Event Specification
Magnitude |
3.1 |
| Date & Time (UTC) | 2013-05-25 10:46:08.6 |
| Date & Time (Local) | 1392/3/4 15:16:08.6 |
| Location | Lat:33.42 Lon: 54.95 |
| Region | Esfahan Province, 150 km North-East of Ardakan |
Nearest Cities |
|
| 21 km West of Mehranjan, Esfahan Province | |
| 36 km North of Hajiabad, Yazd Province | |
| 42 km South West of Khur, Esfahan Province | |
| 47 km South of Farrokhi, Esfahan Province | |
| 58 km South East of Chupanan, Esfahan Province | |
| Depth | 16 km |
| Agency | |
Faults within 150 km: |
|
| BIABANAK_F (Length: 162 km) , Distance to epicenter: 11 km | |
| POSHT_E_BADAM_F (Length: 128 km) , Distance to epicenter: 64 km | |
| SARBALA_F (Length: 92 km) , Distance to epicenter: 81 km | |
| Number of Phases | 8 |
| RMS | 0.3 |
| Number of Stations | 6 |
| Error in Latitude | >5.1 km |
| Error in Longitude | 2.7 km |
| Error in Depth | 7.4 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 89435 | IIEES | YZKH | E | 420.6 | 0.19 | 2013-05-25 10:46:51 | 2013-05-25 12:13:00 | n |
| 89436 | IIEES | NASN | N | 162.1 | 0.28 | 2013-05-25 10:47:12 | 2013-05-25 12:13:00 | n |
| 89437 | IIEES | NASN | E | 142.4 | 0.45 | 2013-05-25 10:47:13 | 2013-05-25 12:13:00 | n |
| 89438 | IIEES | GHVR | E | 47.3 | 0.69 | 2013-05-25 10:48:06 | 2013-05-25 12:13:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | YZKH | Z | Pg | E | 2013-05-25 10:46:28 | -0.05 | y | 118 | 197 | |||
| IIEES | TABS | Z | Pg | E | 2013-05-25 10:46:42 | 0.18 | y | 203 | 82 | |||
| IIEES | TABS | E | Sg | E | 2013-05-25 10:47:06 | 0.15 | y | 203 | 82 | |||
| IIEES | NASN | Z | Pn | E | 2013-05-25 10:46:43 | 0.46 | y | 211 | 252 | |||
| IIEES | NASN | E | Sg | E | 2013-05-25 10:47:08 | -0.28 | y | 211 | 252 | |||
| IIEES | SHRO | Z | Pn | E | 2013-05-25 10:46:53 | -0.46 | y | 304 | 18 | |||
| IIEES | GHVR | Z | Pn | E | 2013-05-25 10:47:01 | 0.34 | y | 362 | 290 | |||
| IIEES | BSRN | Z | Pn | E | 2013-05-25 10:47:08 | -0.43 | y | 423 | 111 | |||
