Event Specification
Magnitude |
3.1 |
| Date & Time (UTC) | 2013-06-13 19:16:00.1 |
| Date & Time (Local) | 1392/3/23 23:46:00.1 |
| Location | Lat:36.45 Lon: 51.72 |
| Region | Mazandaran Province, 29 km South-East of Nowshahr |
Nearest Cities |
|
| 8 km North of Kujur, Mazandaran Province | |
| 12 km North East of Pul, Mazandaran Province | |
| 15 km South of Andarud, Mazandaran Province | |
| 16 km West of Narenj bon, Mazandaran Province | |
| 28 km North East of Void, Mazandaran Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| N_ALBORZ_F (Length: 360 km) , Distance to epicenter: 2 km | |
| KOJOOR (Length: 75 km) , Distance to epicenter: 8 km | |
| KHAZAR_F (Length: 523 km) , Distance to epicenter: 12 km | |
| Number of Phases | 5 |
| RMS | 0.1 |
| Number of Stations | 3 |
| Error in Latitude | >4.6 km |
| Error in Longitude | 6.4 km |
| Error in Depth | 7.5 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 89634 | IIEES | GHVR | E | 153.9 | 0.48 | 2013-06-13 19:17:10 | 2013-06-13 08:42:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | CHTH | Z | Pg | E | 2013-06-13 19:16:13 | -0.26 | y | 80.9 | 222 | |||
| IIEES | CHTH | N | Sg | E | 2013-06-13 19:16:24 | 0.09 | y | 80.9 | 222 | |||
| IIEES | GHVR | Z | Pn | E | 2013-06-13 19:16:35 | 0.05 | y | 223 | 191 | |||
| IIEES | GHVR | N | Sg | E | 2013-06-13 19:17:03 | -0.04 | y | 223 | 191 | |||
| IIEES | ASAO | Z | Pn | E | 2013-06-13 19:16:40 | 0.15 | y | 262 | 217 | |||
