Event Specification
Magnitude |
3.5 |
| Date & Time (UTC) | 2013-07-03 11:30:23.0 |
| Date & Time (Local) | 1392/4/12 16:00:23.0 |
| Location | Lat:27.22 Lon: 54.95 |
| Region | Hormozgan Province, 58 km East of Bastak |
Nearest Cities |
|
| 58 km North East of Bastak, Hormozgan Province | |
| 70 km North East of Jenah, Hormozgan Province | |
| 70 km North West of Bandar-e khamir, Hormozgan Province | |
| 77 km South East of Latifi, Fars Province | |
| 78 km North East of Bandar-e lengeh, Hormozgan Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| MFF1 (Length: 180 km) , Distance to epicenter: 18 km | |
| LAR_F (Length: 99 km) , Distance to epicenter: 45 km | |
| ZFF1 (Length: 165 km) , Distance to epicenter: 49 km | |
| Number of Phases | 5 |
| RMS | 0.1 |
| Number of Stations | 5 |
| Error in Latitude | >5.1 km |
| Error in Longitude | 4.1 km |
| Error in Depth | 7.7 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 89815 | IIEES | BNDS | N | 1072.4 | 0.28 | 2013-07-03 11:30:31 | 2013-07-03 01:38:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | GHIR | Z | Pn | E | 2013-07-03 11:30:58 | 0.06 | y | 226 | 302 | |||
| IIEES | GHIR | E | Sg | E | 2013-07-03 11:31:27 | -0.02 | y | 226 | 302 | |||
| IIEES | YZKH | Z | Pn | E | 2013-07-03 11:31:42 | 0.17 | y | 574 | 357 | |||
| IIEES | CHBR | Z | Pn | E | 2013-07-03 11:31:42 | -0.03 | y | 581 | 107 | |||
| IIEES | NASN | Z | Pn | E | 2013-07-03 11:31:51 | -0.23 | y | 652 | 342 | |||
