Event Specification
Magnitude |
4 |
| Date & Time (UTC) | 2013-07-27 21:39:09.0 |
| Date & Time (Local) | 1392/5/6 02:09:09.0 |
| Location | Lat:36.92 Lon: 56.09 |
| Region | Khorasan(north) Province, 26 km West of Jajarm |
Nearest Cities |
|
| 19 km West of Garmeh, Khorasan(north) Province | |
| 27 km West of Jajarm, Khorasan(north) Province | |
| 30 km South East of Nardin, Semnan Province | |
| 41 km South East of Rezvan, Semnan Province | |
| 41 km East of Qaleh qafeh, Semnan Province | |
| Depth | 18 km |
| Agency | |
Faults within 150 km: |
|
| JAJARAM_F (Length: 77 km) , Distance to epicenter: 14 km | |
| ROBATE_QARABIL_F (Length: 168 km) , Distance to epicenter: 28 km | |
| MEYAMEY_F (Length: 141 km) , Distance to epicenter: 44 km | |
| Number of Phases | 6 |
| RMS | 0.1 |
| Number of Stations | 5 |
| Error in Latitude | >4.4 km |
| Error in Longitude | 5.1 km |
| Error in Depth | 12.2 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 90014 | IIEES | ZNJK | E | 27.8 | 0.28 | 2013-07-27 21:41:54 | 2013-07-27 11:10:00 | n |
| 90015 | IIEES | ZNJK | N | 66.7 | 0.6 | 2013-07-27 21:41:55 | 2013-07-27 11:10:00 | n |
| 90016 | IIEES | GRMI | N | 28 | 0.56 | 2013-07-27 21:42:09 | 2013-07-27 11:10:00 | n |
| 90017 | IIEES | GRMI | E | 42.2 | 0.44 | 2013-07-27 21:42:15 | 2013-07-27 11:10:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | MRVT | Z | Pg | E | 2013-07-27 21:39:23 | -0.02 | y | 81.6 | 360 | |||
| IIEES | MRVT | N | Sg | E | 2013-07-27 21:39:33 | 0.03 | y | 81.6 | 360 | |||
| IIEES | BJRD | Z | Pg | E | 2013-07-27 21:39:33 | -0.01 | y | 145 | 53 | |||
| IIEES | TABS | Z | Pn | E | 2013-07-27 21:40:03 | 0.02 | y | 375 | 165 | |||
| IIEES | ZNJK | Z | Pn | E | 2013-07-27 21:40:38 | 0.07 | y | 662 | 270 | |||
| IIEES | GRMI | Z | Pn | E | 2013-07-27 21:40:49 | -0.12 | y | 751 | 289 | |||
