Event Specification
Magnitude |
2.1 |
| Date & Time (UTC) | 2013-07-30 09:17:41.9 |
| Date & Time (Local) | 1392/5/8 13:47:41.9 |
| Location | Lat:31.98 Lon: 55.85 |
| Region | Yazd Province, 59 km North-East of Bafq |
Nearest Cities |
|
| 21 km North West of Behabad, Yazd Province | |
| 27 km North of Kushk, Yazd Province | |
| 35 km North West of Benestan, Yazd Province | |
| 50 km North West of Asfih, Yazd Province | |
| 56 km North East of Mobarake, Yazd Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| KUHBANAN_F (Length: 189 km) , Distance to epicenter: 6 km | |
| SARBALA_F (Length: 92 km) , Distance to epicenter: 16 km | |
| JAFARABAD_F (Length: 60 km) , Distance to epicenter: 19 km | |
| Number of Phases | 6 |
| RMS | 0.2 |
| Number of Stations | 4 |
| Error in Latitude | >3.4 km |
| Error in Longitude | 4.8 km |
| Error in Depth | 9.7 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 90043 | IIEES | YZKH | N | 30.2 | 0.56 | 2013-07-30 09:18:20 | 2013-07-30 10:52:00 | n |
| 90044 | IIEES | YZKH | E | 34.7 | 0.4 | 2013-07-30 09:18:23 | 2013-07-30 10:52:00 | n |
| 90045 | IIEES | TABS | N | 14.5 | 0.2 | 2013-07-30 09:18:48 | 2013-07-30 10:52:00 | n |
| 90046 | IIEES | KRBR | N | 18.6 | 0.24 | 2013-07-30 09:18:53 | 2013-07-30 10:52:00 | n |
| 90047 | IIEES | KRBR | E | 19 | 0.28 | 2013-07-30 09:18:55 | 2013-07-30 10:52:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | YZKH | Z | Pg | E | 2013-07-30 09:18:03 | 0.41 | y | 127 | 292 | |||
| IIEES | YZKH | E | Sg | E | 2013-07-30 09:18:18 | -0.31 | y | 127 | 292 | |||
| IIEES | TABS | Z | Pn | E | 2013-07-30 09:18:17 | -0.04 | y | 220 | 32 | |||
| IIEES | KRBR | Z | Pn | E | 2013-07-30 09:18:19 | 0.14 | y | 238 | 158 | |||
| IIEES | KRBR | E | Sg | E | 2013-07-30 09:18:49 | -0.11 | y | 238 | 158 | |||
| IIEES | BSRN | Z | Pn | E | 2013-07-30 09:18:28 | -0.12 | y | 310 | 89 | |||
