Event Specification
Magnitude |
1.6 |
| Date & Time (UTC) | 2013-09-02 12:02:11.4 |
| Date & Time (Local) | 1392/6/11 16:32:11.4 |
| Location | Lat:32.08 Lon: 55.49 |
| Region | Yazd Province, 53 km North of Bafq |
Nearest Cities |
|
| 47 km North West of Kushk, Yazd Province | |
| 51 km North of Mobarake, Yazd Province | |
| 54 km North of Bafq, Yazd Province | |
| 56 km North West of Behabad, Yazd Province | |
| 68 km North West of Benestan, Yazd Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| POSHT_E_BADAM_F (Length: 128 km) , Distance to epicenter: 11 km | |
| SARBALA_F (Length: 92 km) , Distance to epicenter: 33 km | |
| KUHBANAN_F (Length: 189 km) , Distance to epicenter: 36 km | |
| Number of Phases | 4 |
| RMS | 0.1 |
| Number of Stations | 3 |
| Error in Latitude | >5.2 km |
| Error in Longitude | 3.3 km |
| Error in Depth | 7.7 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 90435 | IIEES | YZKH | E | 17.4 | 0.36 | 2013-09-02 12:02:40 | 2013-09-03 02:20:00 | n |
| 90436 | IIEES | YZKH | N | 15 | 0.28 | 2013-09-02 12:02:51 | 2013-09-03 02:20:00 | n |
| 90437 | IIEES | TABS | E | 4.1 | 0.72 | 2013-09-02 12:03:21 | 2013-09-03 02:20:00 | n |
| 90438 | IIEES | TABS | N | 7.1 | 0.48 | 2013-09-02 12:03:33 | 2013-09-03 02:20:00 | n |
| 90439 | IIEES | BSRN | N | 2 | 0.4 | 2013-09-02 12:03:56 | 2013-09-03 02:20:00 | n |
| 90440 | IIEES | BSRN | E | 2.1 | 0.4 | 2013-09-02 12:04:02 | 2013-09-03 02:20:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | YZKH | Z | Pg | E | 2013-09-02 12:02:27 | -0.04 | y | 91.6 | 293 | |||
| IIEES | TABS | Z | Pn | E | 2013-09-02 12:02:48 | 0.17 | y | 232 | 41 | |||
| IIEES | TABS | E | Sg | E | 2013-09-02 12:03:17 | -0.07 | y | 232 | 41 | |||
| IIEES | BSRN | Z | Pn | E | 2013-09-02 12:03:01 | -0.07 | y | 344 | 91 | |||
