Event Specification
Magnitude |
3.2 |
| Date & Time (UTC) | 2014-07-01 21:13:45.9 |
| Date & Time (Local) | 1393/4/11 01:43:45.9 |
| Location | Lat:32.13 Lon: 58.93 |
| Region | Khorasan(south) Province, 90 km South-West of Birjand |
Nearest Cities |
|
| 39 km South of Hamand, Khorasan(south) Province | |
| 54 km South of Mazhan, Khorasan(south) Province | |
| 56 km South West of Mokhtaran, Khorasan(south) Province | |
| 66 km South West of Gaz, Khorasan(south) Province | |
| 68 km South East of Bisheh bala, Khorasan(south) Province | |
| Depth | 6 km |
| Agency | |
Faults within 150 km: |
|
| MOHAMMADABAD_F (Length: 71 km) , Distance to epicenter: 96 km | |
| W_NEH_F (Length: 158 km) , Distance to epicenter: 122 km | |
| NOZAD_F (Length: 27 km) , Distance to epicenter: 124 km | |
| Number of Phases | 6 |
| RMS | 0.1 |
| Number of Stations | 6 |
| Error in Latitude | >2.3 km |
| Error in Longitude | 2.8 km |
| Error in Depth | 5.3 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 92717 | IIEES | KRBR | N | 86.6 | 0.32 | 2014-07-01 21:15:28 | 2014-07-01 10:32:00 | n |
| 92718 | IIEES | KRBR | E | 67.1 | 0.48 | 2014-07-01 21:15:29 | 2014-07-01 10:32:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | BSRN | Z | Pg | E | 2014-07-01 21:13:50 | 0 | y | 26.2 | 134 | |||
| IIEES | SHRT | Z | Pn | E | 2014-07-01 21:14:20 | 0.13 | y | 211 | 37 | |||
| IIEES | TABS | Z | Pn | E | 2014-07-01 21:14:24 | -0.15 | y | 239 | 315 | |||
| IIEES | KRBR | Z | Pn | E | 2014-07-01 21:14:34 | 0.18 | y | 315 | 222 | |||
| IIEES | ZHSF | Z | Pn | E | 2014-07-01 21:14:35 | -0.17 | y | 330 | 147 | |||
| IIEES | YZKH | Z | Pn | E | 2014-07-01 21:14:45 | -0.01 | y | 409 | 275 | |||
