Event Specification
Magnitude |
3.2 |
| Date & Time (UTC) | 2017-12-09 13:03:50.5 |
| Date & Time (Local) | 1396/9/18 16:33:50.5 |
| Location | Lat:35.765 Lon: 50.935 |
| Region | Tehran Province, 5 km of Karaj |
Nearest Cities |
|
| 5 km of Karaj, Tehran Province | |
| 12 km North of Malard, Tehran Province | |
| 17 km North West of Shahriyar, Tehran Province | |
| 19 km South of Barghan, Tehran Province | |
| 20 km North of Joqin, Tehran Province | |
| Depth | 17 km |
| Agency | |
Faults within 150 km: |
|
| ESHTEHARD_F (Length: 69 km) , Distance to epicenter: 5 km | |
| N_TEHRAN_F4 (Length: 115 km) , Distance to epicenter: 11 km | |
| MOSHA_F (Length: 234 km) , Distance to epicenter: 30 km | |
| Number of Phases | 13 |
| RMS | 0.3 |
| Number of Stations | 11 |
| Error in Latitude | >2.4 km |
| Error in Longitude | 2.8 km |
| Error in Depth | 3.6 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 123805 | IIEES | CHTH | E | 7637.1 | 0.1 | 2017-12-09 13:04:00 | 2017-12-10 05:28:00 | n |
| 123806 | IIEES | CHTH | N | 9524.1 | 0.26 | 2017-12-09 13:04:00 | 2017-12-10 05:28:00 | n |
| 123807 | IIEES | DAMV | N | 519.5 | 0.22 | 2017-12-09 13:04:19 | 2017-12-10 05:28:00 | n |
| 123808 | IIEES | DAMV | E | 604.7 | 0.14 | 2017-12-09 13:04:19 | 2017-12-10 05:28:00 | n |
| 123809 | IIEES | GHVR | N | 339.2 | 0.29 | 2017-12-09 13:04:38 | 2017-12-10 05:28:00 | n |
| 123810 | IIEES | GHVR | E | 528 | 0.33 | 2017-12-09 13:04:38 | 2017-12-10 05:28:00 | n |
| 123811 | IIEES | GIDE | N | 418.9 | 0.34 | 2017-12-09 13:04:41 | 2017-12-10 05:28:00 | n |
| 123812 | IIEES | GIDE | E | 261.8 | 0.3 | 2017-12-09 13:04:43 | 2017-12-10 05:28:00 | n |
| 123813 | IIEES | ASAO | N | 158.1 | 0.47 | 2017-12-09 13:04:39 | 2017-12-10 05:28:00 | n |
| 123814 | IIEES | ZNJK | N | 95.7 | 0.31 | 2017-12-09 13:04:56 | 2017-12-10 05:28:00 | n |
| 123815 | IIEES | ZNJK | E | 114.9 | 0.26 | 2017-12-09 13:04:56 | 2017-12-10 05:28:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | THKV | Z | Pg | E | 2017-12-09 13:03:55 | 0.66 | y | 17.4 | 343 | |||
| IIEES | CHTH | Z | Pg | E | 2017-12-09 13:03:55 | -0.15 | y | 23.4 | 47 | |||
| IIEES | CHTH | N | Sg | E | 2017-12-09 13:03:59 | -0.17 | y | 23.4 | 47 | |||
| IIEES | DAMV | Z | Pg | E | 2017-12-09 13:04:06 | -0.05 | y | 94.9 | 99 | |||
| IIEES | GHVR | Z | Pg | E | 2017-12-09 13:04:14 | -0.07 | y | 145 | 169 | |||
| IIEES | GIDE | Z | Pg | E | 2017-12-09 13:04:16 | 0.09 | y | 158 | 325 | |||
| IIEES | ASAO | Z | Pg | E | 2017-12-09 13:04:16 | -0.12 | y | 158 | 212 | |||
| IIEES | ZNJK | Z | Pn | E | 2017-12-09 13:04:26 | -0.13 | y | 226 | 297 | |||
| IIEES | ZNJK | N | Sg | E | 2017-12-09 13:04:54 | -0.47 | y | 226 | 297 | |||
| IIEES | KHMZ | Z | Pn | E | 2017-12-09 13:04:28 | -0.05 | y | 242 | 202 | |||
| IIEES | SNGE | Z | Pn | E | 2017-12-09 13:04:40 | 0.53 | y | 334 | 258 | |||
| IIEES | NASN | Z | Pn | E | 2017-12-09 13:04:44 | -0.01 | y | 371 | 152 | |||
| IIEES | GRMI | Z | Pn | E | 2017-12-09 13:04:51 | 0.01 | y | 432 | 322 | |||
